11 IR075ISOPR15 PR1115 Grade PVD Carbide, Indexable Threading Insert

11 IR075ISOPR15 PR1115 Grade PVD Carbide, Indexable Threading Insert

SKU:
TJY18304
$40.89
(No reviews yet)
Width:
1.77 (in)
Height:
0.39 (in)
Depth:
4.13 (in)
Current Stock:
Adding to cart… The item has been added
Description
11 IR075ISOPR15 PR1115 Grade PVD Carbide, Internal, 60 Degree Full Profile, Right-Hand Threading Insert for Metric (M) Threads
Additional Information
Tool Style:
11IR
Insert Size:
11
Insert Grade:
PR1115
Material:
Carbide
Coating Process:
PVD
[IC] Inscribed Circle (mm):
6.35
[S] Thickness (mm):
3.18
[RE] Corner Radius (mm):
0.05
Application:
Internal Threading
Hand:
Right-Hand
Thread Type:
Internal
Thread Profile:
60 Degree Full Profile
Thread Pitch (mm):
M: 0.75
Primary Workpiece Material:
(P) Carbon/Alloy Steel|(M) Stainless Steel
Number of Cutting Edges:
3
Usage Classification:
Continuous
Insert Holding Method:
Screw or Clamp
Unit (inch/mm):
mm
Feature 1:
Insert for Internal Threading with 3 Cutting Edges
Feature 2:
60 Degree Full Profile for Metric (M) threads
Feature 3:
Hard TiAlN base PVD coated super micro-grain carbide
Feature 4:
Application: Superior anti-oxidation performance with well balanced wear resistance and toughness in steel and stainless steel
ANSI Part Number:
11IR075ISOPR1115
ISO Part Number:
11IR075ISO
Old Material Number:
8829834
Compatible Toolholder (Partial):
S…SINR-2, SINR…-11E, SINR…-11
[IC] Inscribed Circle:
1/4"
[S] Thickness:
1/8"
[RE] Corner Radius:
0.002"
