A25RDSKNL1232 Left-Hand, Negative Rake, Coolant-Through Boring Bar

A25RDSKNL1232 Left-Hand, Negative Rake, Coolant-Through Boring Bar

SKU:
THC16045
$271.81
(No reviews yet)
Width:
1.54 (in)
Height:
1.54 (in)
Depth:
14.17 (in)
Current Stock:
Adding to cart… The item has been added
Description
A25RDSKNL1232 Left-Hand, Negative Rake, Double-Clamp Coolant-Through Boring Bar with 75 Degree Lead Angle and 32.00mm Minimum Bore Dia.
Additional Information
Tool Style:
A...DSKN
Material:
Steel
Bar Type:
Steel Shank
Application:
Boring
Hand:
Left-Hand
Rake:
Negative
[KAPR] Tool Entering Angle (Degree):
75
Insert Shape:
90 Degree Square
[DMIN] Minimum Bore Diameter (mm):
32.00
[H] Shank Height (mm):
23.00
[DCON] Connection Diameter (mm):
25.00
Coolant Through (Yes/No):
Yes
Insert Holding Method:
Double Clamp
Unit (inch/mm):
mm
Feature 1:
Firmly clamps the insert in two directions with a single action maintaining good contact between the shim and the insert even during high feed rates
Feature 2:
Adjustable coolant discharge for various applications and insert types
Feature 3:
Improved insert position accuracy with greater insert life
Feature 4:
Improved machining stability
Feature 5:
Increased clamping rigidity
ANSI Part Number:
A25RDSKNL1232
ISO Part Number:
A25R-DSKNL12-32
Compatible Inserts (Partial):
SNMG43…, SNGG43…, SNGA43…
Old Material Number:
8842102
Clamp:
CP-3D
Clamp Screw:
CS-3D
Shim:
DS-42
Shim Screw:
SB-4085TR
Spring:
SP-3D
Nozzle:
DN10
Wrench (for Clamp Screw):
LW-3
Wrench (for Shim Screw):
FT-15
Product Notes:
Right-hand Insert for Left-hand Toolholder
[LF] Functional Length (mm):
200.00
[LH] Head Length (mm):
43.00
[DMIN] Minimum Bore Diameter (Decimal Inch):
1.2598
[H] Shank Height (Decimal Inch):
0.9055
[DCON] Connection Diameter (Decimal Inch):
0.9843
[LF] Functional Length (Decimal Inch):
7.8740
[LH] Head Length (Decimal Inch):
1.6929
