A40TDSKNR1250 Right-Hand, Negative Rake, Coolant-Through Boring Bar
$453.44
(No reviews yet)
Write a Review
A40TDSKNR1250 Right-Hand, Negative Rake, Coolant-Through Boring Bar
A40TDSKNR1250 Right-Hand, Negative Rake, Double-Clamp Coolant-Through Boring Bar with 75 Degree Lead Angle and 50.00mm Minimum Bore Dia.
- Tool Style:
- A...DSKN
- Material:
- Steel
- Bar Type:
- Steel Shank
- Application:
- Boring
- Hand:
- Right-Hand
- Rake:
- Negative
- [KAPR] Tool Entering Angle (Degree):
- 75
- Insert Shape:
- 90 Degree Square
- [DMIN] Minimum Bore Diameter (mm):
- 50.00
- [H] Shank Height (mm):
- 37.00
- [DCON] Connection Diameter (mm):
- 40.00
- Coolant Through (Yes/No):
- Yes
- Insert Holding Method:
- Double Clamp
- Unit (inch/mm):
- mm
- Feature 1:
- Firmly clamps the insert in two directions with a single action maintaining good contact between the shim and the insert even during high feed rates
- Feature 2:
- Adjustable coolant discharge for various applications and insert types
- Feature 3:
- Improved insert position accuracy with greater insert life
- Feature 4:
- Improved machining stability
- Feature 5:
- Increased clamping rigidity
- ANSI Part Number:
- A40TDSKNR1250
- ISO Part Number:
- A40T-DSKNR12-50
- Compatible Inserts (Partial):
- SNMG43…, SNGG43…, SNGA43…
- Old Material Number:
- 8842105
- Clamp:
- CP-3D
- Clamp Screw:
- CS-3D
- Shim:
- DS-42
- Shim Screw:
- SB-4085TR
- Spring:
- SP-3D
- Nozzle:
- DN20
- Wrench (for Clamp Screw):
- LW-3
- Wrench (for Shim Screw):
- FT-15
- Product Notes:
- Left-hand Insert for Right-hand Toolholder
- [LF] Functional Length (mm):
- 300.00
- [LH] Head Length (mm):
- 53.00
- [DMIN] Minimum Bore Diameter (Decimal Inch):
- 1.9685
- [H] Shank Height (Decimal Inch):
- 1.4567
- [DCON] Connection Diameter (Decimal Inch):
- 1.5748
- [LF] Functional Length (Decimal Inch):
- 11.8110
- [LH] Head Length (Decimal Inch):
- 2.0866
