AABWR 1010JX40F, Indexable Turning Toolholder

AABWR 1010JX40F, Indexable Turning Toolholder

SKU:
THC07163
|
UPC:
4960664604067
$143.19
(No reviews yet)
Width:
1.38 (in)
Height:
1.14 (in)
Depth:
5.91 (in)
Current Stock:
Adding to cart… The item has been added
Description
AABWR 1010JX40F, Right-Hand, Positive Rake, 45 Degree Lead Angle, Indexable Turning Toolholder for Swiss, Back Turning Applications
Additional Information
Tool Style:
AABW
Material:
Steel
Application:
Back Turning|Small Parts Machining
Hand:
Right-Hand
Rake:
Positive
[KAPR] Tool Entering Angle (Degree):
45
[CWN] Cutting Width Minimum (mm):
7.00
[CWX] Cutting Width Maximum (mm):
7.00
Insert Shape:
Irregular
[H] Shank Height (mm):
10.00
[B] Shank Width (mm):
10.00
Coolant Through (Yes/No):
No
Insert Holding Method:
Anchor Pin
Unit (inch/mm):
mm
Feature 1:
Right-Hand Toolholder
Feature 2:
Application: Swiss, Back Turning
Feature 3:
Back Clamp Insert Holding Design
Feature 4:
Compatible with Right-Hand ABW15R… Style Inserts
Feature 5:
Easy Insert Replacement; General Use
ANSI Part Number:
AABWR1010JX40F
ISO Part Number:
AABWR1010JX-40F
US Stock:
0
Worldwide Stock:
0
Compatible Inserts (Partial):
ABW15R…
Old Material Number:
8834828
Anchor Pin:
LPA-11
Lock Screw:
HSB4X8R
Wrench (for Lock Screw):
FH-2
[LF] Functional Length (mm):
120.00
[CW] Cutting Width (Decimal Inch):
0.2756
[CW] Cutting Width (mm):
7.00
[CWN] Cutting Width Minimum (Decimal Inch):
0.2756
[CWX] Cutting Width Maximum (Decimal Inch):
0.2756
[H] Shank Height (Decimal Inch):
0.3937
[B] Shank Width (Decimal Inch):
0.3937
[LF] Functional Length (Decimal Inch):
4.7244
