BDMT 170408ERJS PR1225 Grade PVD Carbide, Indexable Milling Insert
$23.65
(No reviews yet)
Write a Review
BDMT 170408ERJS PR1225 Grade PVD Carbide, Indexable Milling Insert
BDMT 170408ERJS PR1225 Grade PVD Carbide, Parallelogram, Positive Rake Angle, Right-Hand Milling Insert for Roughing in (P) Carbon/Alloy Steel, (P) Mold Steel and (M) Austenitic Stainless Steel
- Tool Style:
- BDMT
- Insert Size:
- 170408
- Chipbreaker:
- ER-JS
- Insert Grade:
- PR1225
- Material:
- Carbide
- Coating Process:
- PVD
- [S] Thickness (mm):
- 4.90
- [RE] Corner Radius (mm):
- 0.80
- Application:
- Facing|Helical Milling|Shouldering|Slotting
- Hand:
- Right-Hand
- Rake:
- Positive
- [EPSR] Insert Included Angle (Degree):
- n/a
- Primary Workpiece Material:
- (P) Carbon/Alloy Steel|(P) Mold Steel
- Insert Shape:
- Parallelogram
- Number of Cutting Edges:
- 2
- Cutting Range:
- Roughing
- Insert Holding Method:
- Screw
- Feature 1:
- Insert for Facing, Shouldering, Slotting, Helical Milling
- Feature 2:
- Honed Edge / Low Cutting Force with 2 Cutting Edges
- Feature 3:
- Superior wear and oxidation resistant MEGACOAT on micro grain carbide substrate
- Feature 4:
- Application: Light interrupted to interrupted cutting of stainless steel
- ANSI Part Number:
- BDMT170408ERJSPR1225
- ISO Part Number:
- BDMT170408ER-JS
- US Stock:
- 1190
- Worldwide Stock:
- 540
- Old Material Number:
- 8831728
- Compatible Toolholder (Partial):
- MEC…-17
- [S] Thickness:
- 0.193"
- [RE] Corner Radius:
- 1/32"
