CNMG 432TK PR015S Grade PVD Carbide, Indexable Turning Insert
$13.69
(No reviews yet)
Write a Review
CNMG 432TK PR015S Grade PVD Carbide, Indexable Turning Insert
CNMG 432TK PR015S Grade PVD Carbide, 0 Degree, Diamond, Negative Rake Angle, Neutral Turning Insert for Light Interruption and Medium-Roughing in (S) Heat-Resistant Alloy, (S) Titanium Alloy, (M) Stainless Steel
- Tool Style:
- CNMG
- Insert Size:
- 432
- Chipbreaker:
- TK
- Insert Grade:
- PR015S
- Material:
- Carbide
- Coating Process:
- PVD
- [IC] Inscribed Circle:
- 1/2"
- [IC] Inscribed Circle (mm):
- 12.70
- [S] Thickness:
- 3/16"
- [S] Thickness (mm):
- 4.76
- [RE] Corner Radius:
- 1/32"
- [RE] Corner Radius (mm):
- 0.80
- Application:
- Boring|External Turning|Facing|Internal Facing
- Hand:
- Neutral
- Rake:
- Negative
- [EPSR] Insert Included Angle (Degree):
- 80
- Primary Workpiece Material:
- (M) Stainless Steel|(S) Heat-Resistant Alloy|(S) Titanium Alloy
- Insert Shape:
- 80 Degree Diamond
- Number of Cutting Edges:
- 4
- Usage Classification:
- Light Interruption
- Cutting Range:
- Medium-Roughing
- Insert Holding Method:
- Screw or Clamp
- Feature 1:
- Insert for External Turning, Facing, Boring, Internal Facing
- Feature 2:
- Stainless Steel / HRSA with 4 Cutting Edges
- Feature 3:
- Improved thermal conductivity by optimum distribution of WC coarse grains in the substrate
- Feature 4:
- Resists heat concentration at the cutting edge to promote stable machining
- Feature 5:
- Application: General purpose grade with excellent wear resistance and stability for continuous to light interrupted heat-resistant alloys
- ANSI Part Number:
- CNMG432TKPR015S
- ISO Part Number:
- CNMG432TK
- Old Material Number:
- 8866586
- Compatible Toolholder (Partial):
- DCLNR...-4…|DCLNL...-4…|DCLNR...-12|DCLNL...-12|MCLNR...-4…|MCLNL...-4…|PCLNR...-4…|PCLNL...-4…|PCLNR...-12|PCLNL...-12|HA...PCLNR12…|HA...PCLNL12…|A...DCLNR4…|A...DCLNL4…|A...DCLNR12…|A...DCLNL12…|S…PCLNR4…|S…PCLNL4…|S…PCLNR12…|S…PCLNL12…
