CS82612, Indexable Countersink

CS82612, Indexable Countersink

SKU:
OTM86140
$208.29
(No reviews yet)
Width:
2.25 (in)
Height:
2.25 (in)
Depth:
4.00 (in)
Current Stock:
Adding to cart… The item has been added
Description
CS82612, 1.4640" Max Cutting Diameter, 3/4" Shank Diameter, 1-1/2" Usable Length, 82 Degree, Indexable Countersink
Additional Information
Tool Style:
CS
Material:
Steel
Application:
Countersinking
Hand:
Right-Hand
[DCX] Cutting Diameter Maximum (mm):
37.19
[LU] Usable Length (mm):
38.10
Number of Inserts:
2
Number of Flutes:
2
Shank Type:
Standard Length
Weldon Flat:
No
[DCON] Connection Diameter (mm):
19.05
Coolant Through (Yes/No):
No
Insert Holding Method:
Screw
Unit (inch/mm):
inch
Feature 1:
Countersink For Flat Head Cap Screw Sizes 5/8", 3/4"
Feature 2:
For use with Two TCMT 3252 Inserts
ANSI Part Number:
CS82612
ISO Part Number:
CS82612
US Stock:
0
Worldwide Stock:
0
Compatible Inserts (Partial):
TCMT3252
Old Material Number:
8600746
Insert Screw:
SCR-02
Wrench (for Insert Screw):
FT-15
[EPSR] Insert Included Angle (Degree):
82
[DC] Cutting Diameter (Decimal Inch):
1.4642 - 1.4642
[DC] Cutting Diameter (mm):
37.19 - 37.19
[DCX] Cutting Diameter Maximum (Decimal Inch):
1.4642
[LU] Usable Length (Decimal Inch):
1.5000
[DCON] Connection Diameter (Decimal Inch):
0.7500
[OAL] Overall Length (mm):
89.66
[OAL] Overall Length (Decimal Inch):
3.5299
