DR4080 Series MSTA, Slot Mill Drive Ring

DR4080 Series MSTA, Slot Mill Drive Ring

SKU:
TPC00819
|
UPC:
4960664526635
$231.45
(No reviews yet)
Current Stock:
Adding to cart… The item has been added
Description
DR4080 Series MSTA, Slot Mill Drive Ring with a 40.00mm Connection Bore Diameter for Slotting Applications
Additional Information
Material:
Steel
Application:
Slotting
[DCB] Connection Bore Diameter (mm):
40.00
[DCON] Connection Diameter (mm):
12.00
Unit (inch/mm):
mm
Spare Part Type:
Drive Ring
Feature 1:
MSTA Series Drive Ring
Feature 2:
80.00mm Outside Diameter
Feature 3:
Compatible with MSTA 160N…-…T Toolholders
ANSI Part Number:
DR4080
ISO Part Number:
DR40-80
US Stock:
5
Worldwide Stock:
0
Old Material Number:
8835560
Compatible Toolholder (Partial):
MSTA 160N…-…T
[DCB] Connection Bore Diameter (Decimal Inch):
1.5748
[DCON] Connection Diameter (Decimal Inch):
0.4724
Series Description (PeopleSoft):
MSTA Milling
