GFVR 2525M201A, Face Grooving Toolholder

GFVR 2525M201A, Face Grooving Toolholder

SKU:
THC04936
|
UPC:
4960664009640
$267.28
(No reviews yet)
Width:
1.97 (in)
Height:
1.73 (in)
Depth:
7.13 (in)
Current Stock:
Adding to cart… The item has been added
Description
GFVR 2525M201A, Right-Hand, GFV Style, Face Grooving Toolholder with a 2.20mm Max Depth of Cut for Face Grooving Applications
Additional Information
Tool Style:
GFV
Material:
Steel
Grooving Type:
External Face Grooving
Application:
Face Grooving
Hand:
Right-Hand
[CDX] Max Depth of Cut (mm):
2.20
[CWN] Cutting Width Minimum (mm):
2.00
[CWX] Cutting Width Maximum (mm):
3.40
[DAXN] Minimum Face Groove Diameter (mm):
20.00
[DAXX] Maximum Face Groove Diameter (Decimal Inch):
No Maximum
[DAXX] Maximum Face Groove Diameter (mm):
No Maximum
[H] Shank Height (mm):
25.00
[B] Shank Width (mm):
25.00
Coolant Through (Yes/No):
No
Insert Holding Method:
Top Clamp
Unit (inch/mm):
mm
Feature 1:
Great for various Face Grooving applications
Feature 2:
Compatible with Right-Hand GVFR200-020A, GVFR230-020A, GVFR250-020A, GVFR270-020A, GVFR290-020A, GVFR340-020A, GVFR200-100AR, GVFR250-125AR, GVFR300-150AR style inserts
ANSI Part Number:
GFVR2525M201A
ISO Part Number:
GFVR2525M-201A
US Stock:
0
Worldwide Stock:
39
Compatible Inserts (Partial):
GVFR200-020A, GVFR230-020A, GVFR250-020A, GVFR270-020A, GVFR290-020A, GVFR340-020A, GVFR200-100AR, GVFR250-125AR, GVFR300-150AR
Old Material Number:
8806261
Clamp Set:
CPS-5V
Wrench (for Clamp Screw):
FT-15
Compatible Blade (Partial):
n/a
[LF] Functional Length (mm):
150.00
[LH] Head Length (mm):
23.00
[CW] Cutting Width (Decimal Inch):
0.0787 - 0.1339
[CW] Cutting Width (mm):
2.00 - 3.40
[CDX] Max Depth of Cut (Decimal Inch):
0.0866
[CWN] Cutting Width Minimum (Decimal Inch):
0.0787
[CWX] Cutting Width Maximum (Decimal Inch):
0.1339
[DAXN] Minimum Face Groove Diameter (Decimal Inch):
0.7874
[H] Shank Height (Decimal Inch):
0.9843
[B] Shank Width (Decimal Inch):
0.9843
[LF] Functional Length (Decimal Inch):
5.9055
[LH] Head Length (Decimal Inch):
0.9055
