GFVR 2525M352B, Face Grooving Toolholder
$267.28
(No reviews yet)
Write a Review
GFVR 2525M352B, Face Grooving Toolholder
GFVR 2525M352B, Right-Hand, GFV Style, Face Grooving Toolholder with a 5.10mm Max Depth of Cut for Face Grooving Applications
- Tool Style:
- GFV
- Material:
- Steel
- Grooving Type:
- External Face Grooving
- Application:
- Face Grooving
- Hand:
- Right-Hand
- [CDX] Max Depth of Cut (mm):
- 5.10
- [CWN] Cutting Width Minimum (mm):
- 4.00
- [CWX] Cutting Width Maximum (mm):
- 4.90
- [DAXN] Minimum Face Groove Diameter (mm):
- 35.00
- [DAXX] Maximum Face Groove Diameter (Decimal Inch):
- 1.9685
- [DAXX] Maximum Face Groove Diameter (mm):
- 50.00
- [H] Shank Height (mm):
- 25.00
- [B] Shank Width (mm):
- 25.00
- Coolant Through (Yes/No):
- No
- Insert Holding Method:
- Top Clamp
- Unit (inch/mm):
- mm
- Feature 1:
- Great for various Face Grooving applications
- Feature 2:
- Compatible with Right-Hand GVFR400-020B, GVFR430-020B, GVFR460-020B, GVFR490-020B, GVFR400-020B, GVFR400-200BR style inserts
- ANSI Part Number:
- GFVR2525M352B
- ISO Part Number:
- GFVR2525M-352B
- US Stock:
- 0
- Worldwide Stock:
- 0
- Compatible Inserts (Partial):
- GVFR400-020B, GVFR430-020B, GVFR460-020B, GVFR490-020B, GVFR400-020B, GVFR400-200BR
- Old Material Number:
- 8810907
- Clamp Set:
- CPS-6V
- Wrench (for Clamp Screw):
- LW-3
- [LF] Functional Length (mm):
- 150.00
- [LH] Head Length (mm):
- 30.00
- [CW] Cutting Width (Decimal Inch):
- 0.1575 - 0.1929
- [CW] Cutting Width (mm):
- 4.00 - 4.90
- [CDX] Max Depth of Cut (Decimal Inch):
- 0.2008
- [CWN] Cutting Width Minimum (Decimal Inch):
- 0.1575
- [CWX] Cutting Width Maximum (Decimal Inch):
- 0.1929
- [DAXN] Minimum Face Groove Diameter (Decimal Inch):
- 1.3780
- [H] Shank Height (Decimal Inch):
- 0.9843
- [B] Shank Width (Decimal Inch):
- 0.9843
- [LF] Functional Length (Decimal Inch):
- 5.9055
- [LH] Head Length (Decimal Inch):
- 1.1811
