GFVSR 2525M1001C, Face Grooving Toolholder
$317.40
(No reviews yet)
Write a Review
GFVSR 2525M1001C, Face Grooving Toolholder
GFVSR 2525M1001C, Right-Hand, GFVS Style, Face Grooving Toolholder with a 6.60mm Max Depth of Cut for Face Grooving Applications
- Tool Style:
- GFVS
- Material:
- Steel
- Grooving Type:
- External Face Grooving
- Application:
- Face Grooving
- Hand:
- Right-Hand
- [CDX] Max Depth of Cut (mm):
- 6.60
- [CWN] Cutting Width Minimum (mm):
- 3.50
- [CWX] Cutting Width Maximum (mm):
- 4.50
- [DAXN] Minimum Face Groove Diameter (mm):
- 100.00
- [DAXX] Maximum Face Groove Diameter (Decimal Inch):
- 5.9055
- [DAXX] Maximum Face Groove Diameter (mm):
- 150.00
- [H] Shank Height (mm):
- 25.00
- [B] Shank Width (mm):
- 25.00
- Coolant Through (Yes/No):
- No
- Insert Holding Method:
- Top Clamp
- Unit (inch/mm):
- mm
- Feature 1:
- Great for various Face Grooving applications
- Feature 2:
- Compatible with Left-Hand GVFL350-040C, GVFL400-040C, GVFL450-040C, GVFL350-020C, GVFL400-020C, GVFL350-040C, GVFL400-040C style inserts
- ANSI Part Number:
- GFVSR2525M1001C
- ISO Part Number:
- GFVSR2525M-1001C
- US Stock:
- 0
- Worldwide Stock:
- 1
- Compatible Inserts (Partial):
- GVFL350-040C, GVFL400-040C, GVFL450-040C, GVFL350-020C, GVFL400-020C, GVFL350-040C, GVFL400-040C
- Old Material Number:
- 8810949
- Clamp Set:
- CPS-8V
- Blade:
- SFR-1001C
- Blade Screw:
- HH4X12
- Wrench (for Clamp Screw):
- LW-4
- Compatible Blade (Partial):
- SFR1001C
- [LF] Functional Length (mm):
- 150.00
- [LH] Head Length (mm):
- 32.00
- Product Notes:
- Left-hand Insert for Right-hand Toolholder
- [CW] Cutting Width (Decimal Inch):
- 0.1378 - 0.1772
- [CW] Cutting Width (mm):
- 3.50 - 4.50
- [CDX] Max Depth of Cut (Decimal Inch):
- 0.2598
- [CWN] Cutting Width Minimum (Decimal Inch):
- 0.1378
- [CWX] Cutting Width Maximum (Decimal Inch):
- 0.1772
- [DAXN] Minimum Face Groove Diameter (Decimal Inch):
- 3.9370
- [H] Shank Height (Decimal Inch):
- 0.9843
- [B] Shank Width (Decimal Inch):
- 0.9843
- [LF] Functional Length (Decimal Inch):
- 5.9055
- [LH] Head Length (Decimal Inch):
- 1.2598
