KFTBL 901505S, Face Grooving Blade

KFTBL 901505S, Face Grooving Blade

SKU:
THF05155
|
UPC:
4960664158447
$284.05
(No reviews yet)
Width:
2.13 (in)
Height:
0.24 (in)
Depth:
6.69 (in)
Current Stock:
Adding to cart… The item has been added
Description
KFTBL 901505S, Left-Hand, Tool Block Style, Face Grooving Blade with a 90.00mm Minimum Face Groove Diameter for Face Grooving Applications
Additional Information
Tool Style:
KFTB
Material:
Steel
Grooving Type:
Face Grooving
Application:
Face Grooving
Hand:
Left-Hand
[CDX] Max Depth of Cut (mm):
30.00
[CWN] Cutting Width Minimum (mm):
5.00
[CWX] Cutting Width Maximum (mm):
5.00
[DAXN] Minimum Face Groove Diameter (mm):
90.00
[DAXX] Maximum Face Groove Diameter (Decimal Inch):
5.9055
[DAXX] Maximum Face Groove Diameter (mm):
150.00
Coolant Through (Yes/No):
No
Insert Holding Method:
Self-Clamp
Unit (inch/mm):
mm
Feature 1:
Left-Hand Face Grooving Tool Block
Feature 2:
Max Depth of Cut 30.00mm
Feature 3:
Compatible with toolholder KTKTB… and FTk9 inserts
ANSI Part Number:
KFTBL901505S
ISO Part Number:
KFTBL90150-5S
US Stock:
0
Worldwide Stock:
13
Compatible Inserts (Partial):
FTK5
Old Material Number:
8812174
Compatible Toolholder (Partial):
KTKTB…
[LF] Functional Length (mm):
150.00
[CW] Cutting Width (Decimal Inch):
0.1969
[CW] Cutting Width (mm):
5.00
[CDX] Max Depth of Cut (Decimal Inch):
1.1811
[CWN] Cutting Width Minimum (Decimal Inch):
0.1969
[CWX] Cutting Width Maximum (Decimal Inch):
0.1969
[DAXN] Minimum Face Groove Diameter (Decimal Inch):
3.5433
[LF] Functional Length (Decimal Inch):
5.9055
