KFTBR 1502504S, Face Grooving Blade

KFTBR 1502504S, Face Grooving Blade

SKU:
THF05120
|
UPC:
4960664158393
$284.05
(No reviews yet)
Width:
2.13 (in)
Height:
0.24 (in)
Depth:
6.69 (in)
Current Stock:
Adding to cart… The item has been added
Description
KFTBR 1502504S, Right-Hand, Tool Block Style, Face Grooving Blade with a 140.00mm Minimum Face Groove Diameter for Face Grooving Applications
Additional Information
Tool Style:
KFTB
Material:
Steel
Grooving Type:
Face Grooving
Application:
Face Grooving
Hand:
Right-Hand
[CDX] Max Depth of Cut (mm):
30.00
[CWN] Cutting Width Minimum (mm):
4.00
[CWX] Cutting Width Maximum (mm):
4.00
[DAXN] Minimum Face Groove Diameter (mm):
140.00
[DAXX] Maximum Face Groove Diameter (Decimal Inch):
9.8425
[DAXX] Maximum Face Groove Diameter (mm):
250.00
Coolant Through (Yes/No):
No
Insert Holding Method:
Self-Clamp
Unit (inch/mm):
mm
Feature 1:
Right-Hand Face Grooving Tool Block
Feature 2:
Max Depth of Cut 30.00mm
Feature 3:
Compatible with toolholder KTKTB… and FTK4 inserts
ANSI Part Number:
KFTBR1502504S
ISO Part Number:
KFTBR150250-4S
US Stock:
0
Worldwide Stock:
17
Compatible Inserts (Partial):
FTK4
Old Material Number:
8812175
Compatible Toolholder (Partial):
KTKTB…
[LF] Functional Length (mm):
150.00
[CW] Cutting Width (Decimal Inch):
0.1575
[CW] Cutting Width (mm):
4.00
[CDX] Max Depth of Cut (Decimal Inch):
1.1811
[CWN] Cutting Width Minimum (Decimal Inch):
0.1575
[CWX] Cutting Width Maximum (Decimal Inch):
0.1575
[DAXN] Minimum Face Groove Diameter (Decimal Inch):
5.5118
[LF] Functional Length (Decimal Inch):
5.9055
