KGBR 2020K2235, External Grooving Toolholder

KGBR 2020K2235, External Grooving Toolholder

SKU:
THC04210
|
UPC:
4960664008841
$158.71
(No reviews yet)
Width:
1.58 (in)
Height:
1.38 (in)
Depth:
5.91 (in)
Current Stock:
Adding to cart… The item has been added
Description
KGBR 2020K2235, Right-Hand, External Grooving Toolholder with a 5.50mm Max Depth of Cut for Shallow Grooving Applications
Additional Information
Tool Style:
KGB
Material:
Steel
Grooving Type:
External Grooving
Application:
Shallow Grooving
Hand:
Right-Hand
[CDX] Max Depth of Cut (mm):
5.50
[CWN] Cutting Width Minimum (mm):
3.50
[CWX] Cutting Width Maximum (mm):
4.80
[H] Shank Height (mm):
20.00
[B] Shank Width (mm):
20.00
Coolant Through (Yes/No):
No
Insert Holding Method:
Top Clamp
Unit (inch/mm):
mm
Feature 1:
Great for various Shallow Grooving applications
Feature 2:
Compatible with GBA43R... style inserts
ANSI Part Number:
KGBR2020K2235
ISO Part Number:
KGBR2020K22-35
US Stock:
0
Worldwide Stock:
18
Compatible Inserts (Partial):
GBA43R…
Old Material Number:
8806325
[LF] Functional Length (mm):
125.00
[LH] Head Length (mm):
25.50
[CW] Cutting Width (Decimal Inch):
0.1378 - 0.1890
[CW] Cutting Width (mm):
3.50 - 4.80
[CDX] Max Depth of Cut (Decimal Inch):
0.2165
[CWN] Cutting Width Minimum (Decimal Inch):
0.1378
[CWX] Cutting Width Maximum (Decimal Inch):
0.1890
[H] Shank Height (Decimal Inch):
0.7874
[B] Shank Width (Decimal Inch):
0.7874
[LF] Functional Length (Decimal Inch):
4.9213
[LH] Head Length (Decimal Inch):
1.0039
