KGDL 4T25C, External Grooving & Cut-Off Blade

KGDL 4T25C, External Grooving & Cut-Off Blade

SKU:
THT03571
|
UPC:
4960664614196
$108.50
(No reviews yet)
Width:
1.97 (in)
Height:
0.39 (in)
Depth:
3.15 (in)
Current Stock:
Adding to cart… The item has been added
Description
KGDL 4T25C SwitchBlade Style, Left-Hand Grooving & Cut-Off Blade with a 25mm Max. Groove Depth for External Grooving, Cut-Off Applications
Additional Information
Tool Style:
KGD
Material:
Steel
Grooving Type:
External Grooving
Application:
Cut-Off|External Grooving
Hand:
Left-Hand
[CDX] Max Depth of Cut (mm):
25.20
[CWN] Cutting Width Minimum (mm):
4.00
[CWX] Cutting Width Maximum (mm):
5.00
Coolant Through (Yes/No):
No
Insert Holding Method:
Screw
Unit (inch/mm):
mm
Feature 1:
Left-Hand Blade
Feature 2:
Application: External Grooving, Cut-Off
Feature 3:
Clamp Screw Insert Holding Design
Feature 4:
Compatible with KGDL…C, KGDSR…C Toolholders
Feature 5:
Compatible with Left-Hand GDM4…, GDMS4…, GDG4…, GDM5…, GDMS5…, GDG5… Inserts
ANSI Part Number:
KGDL4T25C
ISO Part Number:
KGDL-4T25-C
US Stock:
2
Worldwide Stock:
12
Compatible Inserts (Partial):
GDM4…, GDMS4…, GDG4…, GDM5…, GDMS5…, GDG5…
Old Material Number:
8834779
Compatible Toolholder (Partial):
KGDL…C, KGDSR…C
[CW] Cutting Width (Decimal Inch):
0.1575 - 0.1969
[CW] Cutting Width (mm):
4.00 - 5.00
[CDX] Max Depth of Cut (Decimal Inch):
0.9921
[CWN] Cutting Width Minimum (Decimal Inch):
0.1575
[CWX] Cutting Width Maximum (Decimal Inch):
0.1969
