KGDR 122T17, External Grooving Toolholder

KGDR 122T17, External Grooving Toolholder

SKU:
THT05080
|
UPC:
4960664636808
$175.37
(No reviews yet)
Width:
1.54 (in)
Height:
1.54 (in)
Depth:
8.27 (in)
Current Stock:
Adding to cart… The item has been added
Description
KGDR 122T17, Right-Hand, External Grooving Toolholder with a 0.6693" Max Depth of Cut for Grooving and Cut-Off Applications
Additional Information
Tool Style:
KGD
Material:
Steel
Grooving Type:
External Grooving
Application:
Cut-Off|External Grooving
Hand:
Right-Hand
[CDX] Max Depth of Cut (mm):
17.00
[CWN] Cutting Width Minimum (mm):
2.00
[CWX] Cutting Width Maximum (mm):
3.00
[H] Shank Height (mm):
19.05
[B] Shank Width (mm):
19.05
Coolant Through (Yes/No):
No
Insert Holding Method:
Screw
Unit (inch/mm):
inch
Feature 1:
Improved insert clamping force generated by an innovative toolholder design
Feature 2:
Smooth chip control with numerous chipbreakers to choose from for a variety of workpieces
Feature 3:
Compatible with GDM2…, GDMS2…, GDG2…, GDGS2…, GDM3…, GDMS3…, GDG3…, GDGS3… Inserts
ANSI Part Number:
KGDR122T17
ISO Part Number:
KGDR12-2T17
US Stock:
0
Worldwide Stock:
0
Compatible Inserts (Partial):
GDM2…, GDMS2…, GDG2…, GDGS2…, GDM3…, GDMS3…, GDG3…, GDGS3…
Old Material Number:
8838479
Clamp Screw:
HH5X16
Wrench (for Clamp Screw):
LW-4
Tightening Torque:
6.5 Nm
[LF] Functional Length (mm):
124.97
[LH] Head Length (mm):
32.50
[CW] Cutting Width (Decimal Inch):
0.0787 - 0.1181
[CW] Cutting Width (mm):
2.00 - 3.00
[CDX] Max Depth of Cut (Decimal Inch):
0.6693
[CWN] Cutting Width Minimum (Decimal Inch):
0.0787
[CWX] Cutting Width Maximum (Decimal Inch):
0.1181
[H] Shank Height (Decimal Inch):
0.7500
[B] Shank Width (Decimal Inch):
0.7500
[LF] Functional Length (Decimal Inch):
4.9201
[LH] Head Length (Decimal Inch):
1.2795
