KGDR 5T25C, External Grooving & Cut-Off Blade

KGDR 5T25C, External Grooving & Cut-Off Blade

SKU:
THT03578
|
UPC:
4960664614226
$108.50
(No reviews yet)
Width:
1.97 (in)
Height:
0.39 (in)
Depth:
3.15 (in)
Current Stock:
Adding to cart… The item has been added
Description
KGDR 5T25C SwitchBlade Style, Right-Hand Grooving & Cut-Off Blade with a 25mm Max. Groove Depth for External Grooving, Cut-Off Applications
Additional Information
Tool Style:
KGD
Material:
Steel
Grooving Type:
External Grooving
Application:
Cut-Off|External Grooving
Hand:
Right-Hand
[CDX] Max Depth of Cut (mm):
25.20
[CWN] Cutting Width Minimum (mm):
5.00
[CWX] Cutting Width Maximum (mm):
6.00
Coolant Through (Yes/No):
No
Insert Holding Method:
Screw
Unit (inch/mm):
mm
Feature 1:
Right-Hand Blade
Feature 2:
Application: External Grooving, Cut-Off
Feature 3:
Clamp Screw Insert Holding Design
Feature 4:
Compatible with KGDR…C, KGDSL…C Toolholders
Feature 5:
Compatible with Right-Hand GDM5…, GDMS5…, GDG5…, GDM6…, GDMS6…, GDG6… Inserts
ANSI Part Number:
KGDR5T25C
ISO Part Number:
KGDR-5T25-C
US Stock:
11
Worldwide Stock:
1
Compatible Inserts (Partial):
GDM5…, GDMS5…, GDG5…, GDM6…, GDMS6…, GDG6…
Old Material Number:
8834808
Compatible Toolholder (Partial):
KGDR…C, KGDSL…C
[CW] Cutting Width (Decimal Inch):
0.1969 - 0.2362
[CW] Cutting Width (mm):
5.00 - 6.00
[CDX] Max Depth of Cut (Decimal Inch):
0.9921
[CWN] Cutting Width Minimum (Decimal Inch):
0.1969
[CWX] Cutting Width Maximum (Decimal Inch):
0.2362
