KGML 2525M3T20, External Grooving Toolholder
$217.15
(No reviews yet)
Write a Review
KGML 2525M3T20, External Grooving Toolholder
KGML 2525M3T20, Left-Hand, External Grooving Toolholder with a 20.00mm Max Depth of Cut for Grooving and Cut-Off Applications
- Tool Style:
- KGM
- Material:
- Steel
- Grooving Type:
- External Grooving
- Application:
- Cut-Off|External Grooving
- Hand:
- Left-Hand
- [CDX] Max Depth of Cut (mm):
- 20.00
- [CWN] Cutting Width Minimum (mm):
- 3.00
- [CWX] Cutting Width Maximum (mm):
- 4.00
- [H] Shank Height (mm):
- 25.00
- [B] Shank Width (mm):
- 25.00
- Coolant Through (Yes/No):
- No
- Insert Holding Method:
- Screw
- Unit (inch/mm):
- mm
- Feature 1:
- Great for various Grooving and Cut-Off applications
- Feature 2:
- Compatible with GMM3…, GMG3…, GMN3…, GMR3…, GML3…, FGGR3…, FGGL3…, GMM4…, GMG4…, GMN4…, GMR4…, GML4…, FGGR4…, FGGL4… style inserts
- ANSI Part Number:
- KGML2525M3T20
- ISO Part Number:
- KGML2525M-3T20
- Compatible Inserts (Partial):
- GMM3…, GMG3…, GMN3…, GMR3…, GML3…, FGGR3…, FGGL3…, GMM4…, GMG4…, GMN4…, GMR4…, GML4…, FGGR4…, FGGL4…
- Old Material Number:
- 8806354
- Clamp Screw:
- HH5X25
- Wrench (for Clamp Screw):
- LW-4
- [LF] Functional Length (mm):
- 150.00
- [LH] Head Length (mm):
- 36.00
- [CW] Cutting Width (Decimal Inch):
- 0.1181 - 0.1575
- [CW] Cutting Width (mm):
- 3.00 - 4.00
- [CDX] Max Depth of Cut (Decimal Inch):
- 0.7874
- [CWN] Cutting Width Minimum (Decimal Inch):
- 0.1181
- [CWX] Cutting Width Maximum (Decimal Inch):
- 0.1575
- [H] Shank Height (Decimal Inch):
- 0.9843
- [B] Shank Width (Decimal Inch):
- 0.9843
- [LF] Functional Length (Decimal Inch):
- 5.9055
- [LH] Head Length (Decimal Inch):
- 1.4173
