KPKB26-4, Cut-Off Blade

KPKB26-4, Cut-Off Blade

SKU:
THP06799
|
UPC:
4960664932948
$113.56
(No reviews yet)
Width:
1.58 (in)
Height:
1.38 (in)
Depth:
5.91 (in)
Current Stock:
Adding to cart… The item has been added
Description
KPKB26-4, Neutral, Cut-Off Blade with a 80.00mm Maximum Cut-Off Diameter for Cut-Off Applications
Additional Information
Tool Style:
KPKB
Material:
Steel
Application:
Cut-Off
Hand:
Neutral
[CWN] Cutting Width Minimum (mm):
4.00
[CWX] Cutting Width Maximum (mm):
4.00
[CUTDIA] Maximum Cut-Off Diameter (Decimal Inch):
3.1496
[CUTDIA] Maximum Cut-Off Diameter (mm):
80.00
Coolant Through (Yes/No):
No
Insert Holding Method:
Self-Clamp
Unit (inch/mm):
mm
Feature 1:
Neutral KPKB Series, Cut-Off Blade
Feature 2:
Maximum Cut-Off Diameter 80.00mm
Feature 3:
Compatible with KPKTB…-26JCT, KTKTB…-26 Tool Blocks and PKM40… Inserts
ANSI Part Number:
KPKB264
ISO Part Number:
KPKB26-4
US Stock:
4
Worldwide Stock:
8
Compatible Inserts (Partial):
PKM40…
Old Material Number:
8865586
Wrench (for Insert Release):
LPW-5
Compatible Tool Block (Partial):
KPKTB…-26JCT, KTKTB…-26
[LF] Functional Length (mm):
110.00
[CW] Cutting Width (Decimal Inch):
0.1575
[CW] Cutting Width (mm):
4.00
[CWN] Cutting Width Minimum (Decimal Inch):
0.1575
[CWX] Cutting Width Maximum (Decimal Inch):
0.1575
[LF] Functional Length (Decimal Inch):
4.3307
