KPKHR 122JCT, Cut-Off Toolholder

KPKHR 122JCT, Cut-Off Toolholder

SKU:
THP06867
|
UPC:
4960664993079
$183.65
(No reviews yet)
Width:
1.54 (in)
Height:
1.54 (in)
Depth:
8.27 (in)
Current Stock:
Adding to cart… The item has been added
Description
KPKHR 122JCT Cut-Off, Right-Hand, Cut-Off Toolholder with a 1.4961" Maximum Cut-Off Diameter for Cut-Off Applications
Additional Information
Tool Style:
KPKH-JCT
Material:
Steel
Application:
Cut-Off
Hand:
Right-Hand
[CWN] Cutting Width Minimum (mm):
2.00
[CWX] Cutting Width Maximum (mm):
2.40
[CUTDIA] Maximum Cut-Off Diameter (Decimal Inch):
1.5000
[CUTDIA] Maximum Cut-Off Diameter (mm):
38.10
[H] Shank Height (mm):
19.05
[B] Shank Width (mm):
19.05
Coolant Through (Yes/No):
Yes
Insert Holding Method:
Self-Clamp
Unit (inch/mm):
inch
Coolant Pressure Resistance (psi):
~2,175
Feature 1:
Easy self-clamping insert replacement
Feature 2:
Firm Insert Clamp Ensures Added Safety and Security
Feature 3:
Compatible with PKM20…, PKM24…. Inserts
ANSI Part Number:
KPKHR122JCT
ISO Part Number:
KPKHR12-2JCT
US Stock:
10
Worldwide Stock:
0
Compatible Inserts (Partial):
PKM20…, PKM24…
Old Material Number:
8867910
Plug 1:
HSG1/8X8.0
Wrench (for Insert Release):
LPW-5
[LF] Functional Length (mm):
127.00
[LH] Head Length (mm):
35.10
[CW] Cutting Width (Decimal Inch):
0.0787 - 0.0945
[CW] Cutting Width (mm):
2.00 - 2.40
[CWN] Cutting Width Minimum (Decimal Inch):
0.0787
[CWX] Cutting Width Maximum (Decimal Inch):
0.0945
[H] Shank Height (Decimal Inch):
0.7500
[B] Shank Width (Decimal Inch):
0.7500
[LF] Functional Length (Decimal Inch):
5.0000
[LH] Head Length (Decimal Inch):
1.3819
