KPKHR 2525M3D45, Cut-Off Toolholder

KPKHR 2525M3D45, Cut-Off Toolholder

SKU:
THP06815
|
UPC:
4960664955282
$140.60
(No reviews yet)
Width:
1.54 (in)
Height:
1.54 (in)
Depth:
8.27 (in)
Current Stock:
Adding to cart… The item has been added
Description
KPKHR 2525M3D45, Right-Hand, Cut-Off Toolholder with a 45.00mm Maximum Cut-Off Diameter for Cut-Off Applications
Additional Information
Tool Style:
KPKH
Material:
Steel
Application:
Cut-Off
Hand:
Right-Hand
[CWN] Cutting Width Minimum (mm):
3.00
[CWX] Cutting Width Maximum (mm):
3.00
[CUTDIA] Maximum Cut-Off Diameter (Decimal Inch):
1.7717
[CUTDIA] Maximum Cut-Off Diameter (mm):
45.00
[H] Shank Height (mm):
25.00
[B] Shank Width (mm):
25.00
Coolant Through (Yes/No):
No
Insert Holding Method:
Self-Clamp
Unit (inch/mm):
mm
Feature 1:
Easy self-clamping insert replacement
Feature 2:
Firm Insert Clamp Ensures Added Safety and Security
Feature 3:
Compatible with PKM30… Inserts
ANSI Part Number:
KPKHR2525M3D45
ISO Part Number:
KPKHR2525M-3D45
US Stock:
0
Worldwide Stock:
20
Compatible Inserts (Partial):
PKM30…
Old Material Number:
8867176
Wrench (for Insert Release):
LPW-5
[LF] Functional Length (mm):
150.00
[LH] Head Length (mm):
32.50
[CW] Cutting Width (Decimal Inch):
0.1181
[CW] Cutting Width (mm):
3.00
[CWN] Cutting Width Minimum (Decimal Inch):
0.1181
[CWX] Cutting Width Maximum (Decimal Inch):
0.1181
[H] Shank Height (Decimal Inch):
0.9843
[B] Shank Width (Decimal Inch):
0.9843
[LF] Functional Length (Decimal Inch):
5.9055
[LH] Head Length (Decimal Inch):
1.2795
