KPKTB19 26JCT, Cut-Off Tool Block

KPKTB19 26JCT, Cut-Off Tool Block

SKU:
THP06839
$432.60
(No reviews yet)
Width:
2.48 (in)
Height:
2.01 (in)
Depth:
6.61 (in)
Current Stock:
Adding to cart… The item has been added
Description
KPKTB19 26JCT, Neutral, Cut-Off Tool Block with a 0.7500" Shank Height for Cut-Off Applications
Additional Information
Tool Style:
KPKTB-JCT
Material:
Steel
Application:
Cut-Off
Hand:
Neutral
[H] Shank Height (mm):
19.05
[B] Shank Width (mm):
18.30
Coolant Through (Yes/No):
Yes
Unit (inch/mm):
inch
Coolant Pressure Resistance (psi):
1,015
Feature 1:
KTKTB-JCT Neutral Cut-Off Tool Block
Feature 2:
0.7500" Shank Height
Feature 3:
Compatible with KPKB26-…JCT, KTKB26-… Blades
ANSI Part Number:
KPKTB1926JCT
ISO Part Number:
KPKTB19-26JCT
US Stock:
0
Worldwide Stock:
0
Old Material Number:
8609695
Clamp Set:
BCS-2
Clamp Screw:
HH6X16
Coolant Plug:
HSG1/8X8.0
Coolant Plug Screw:
HS3X4
O-Ring:
GR-020
Wrench (for Clamp Screw):
LW-5
Compatible Blade (Partial):
KPKB26-…JCT, KTKB26-…
[H] Shank Height (Decimal Inch):
0.7500
[B] Shank Width (Decimal Inch):
0.7205
[OAL] Overall Length (mm):
86.00
[OAL] Overall Length (Decimal Inch):
3.3858
