KPKTB20 26JCT, Cut-Off Tool Block

KPKTB20 26JCT, Cut-Off Tool Block

SKU:
THP06807
|
UPC:
4960664933020
$432.60
(No reviews yet)
Width:
2.76 (in)
Height:
2.76 (in)
Depth:
3.54 (in)
Current Stock:
Adding to cart… The item has been added
Description
KPKTB20 26JCT, Neutral, Cut-Off Tool Block with a 20.00mm Shank Height for Cut-Off Applications
Additional Information
Tool Style:
KPKTB-JCT
Material:
Steel
Application:
Cut-Off
Hand:
Neutral
[H] Shank Height (mm):
20.00
[B] Shank Width (mm):
19.00
Coolant Through (Yes/No):
Yes
Insert Holding Method:
n/a
Unit (inch/mm):
mm
Coolant Pressure Resistance (psi):
1,015
Feature 1:
KTKTB-JCT Neutral Cut-Off Tool Block
Feature 2:
20.00mm Shank Height
Feature 3:
Compatible with KPKB26-…JCT, KTKB26-… Blades
ANSI Part Number:
KPKTB2026JCT
ISO Part Number:
KPKTB20-26JCT
US Stock:
0
Worldwide Stock:
24
Old Material Number:
8865594
Clamp Set:
BCS-2 (Switchblade Type)
Clamp Screw:
HH6x16
Plug 1:
HS3x4
Plug 2:
HSG1/8X8.0
O-Ring:
GR-020
Wrench (for Clamp Screw):
LW-5
Compatible Blade (Partial):
KPKB26-…JCT, KTKB26-…
[H] Shank Height (Decimal Inch):
0.7874
[B] Shank Width (Decimal Inch):
0.7480
[OAL] Overall Length (mm):
86.00
[OAL] Overall Length (Decimal Inch):
3.3858
