KTKB 261SS, Cut-Off Blade

KTKB 261SS, Cut-Off Blade

SKU:
THP05309
|
UPC:
4960664343409
$112.17
(No reviews yet)
Width:
2.13 (in)
Height:
0.24 (in)
Depth:
6.69 (in)
Current Stock:
Adding to cart… The item has been added
Description
KTKB 261SS, Neutral, Cut-Off Blade with a 35.00mm Maximum Cut-Off Diameter for Cut-Off Applications
Additional Information
Tool Style:
KTKB-SS
Material:
Steel
Application:
Cut-Off
Hand:
Neutral
[CWN] Cutting Width Minimum (mm):
1.60
[CWX] Cutting Width Maximum (mm):
1.60
[CUTDIA] Maximum Cut-Off Diameter (Decimal Inch):
1.3780
[CUTDIA] Maximum Cut-Off Diameter (mm):
35.00
Coolant Through (Yes/No):
No
Insert Holding Method:
Self-Clamp
Unit (inch/mm):
mm
Feature 1:
Neutral KTKB Series, Cut-Off Blade
Feature 2:
Maximum Cut-Off Diameter 35.00mm
Feature 3:
Compatible with KTKTB…-26 Tool Blocks and TKN1.6, TKN1.6-P, TK…1.6, TK…1.6-P Inserts
ANSI Part Number:
KTKB261SS
ISO Part Number:
KTKB26-1SS
US Stock:
1
Worldwide Stock:
23
Compatible Inserts (Partial):
TKN1.6, TKN1.6-P, TK…1.6, TK…1.6-P
Old Material Number:
8806408
Wrench (for Insert Release):
LTK-5
Compatible Tool Block (Partial):
KTKTB…-26
[LF] Functional Length (mm):
110.00
[CW] Cutting Width (Decimal Inch):
0.0630
[CW] Cutting Width (mm):
1.60
[CWN] Cutting Width Minimum (Decimal Inch):
0.0630
[CWX] Cutting Width Maximum (Decimal Inch):
0.0630
[LF] Functional Length (Decimal Inch):
4.3307
