KTKB 324S, Cut-Off Blade

KTKB 324S, Cut-Off Blade

SKU:
THP05230
|
UPC:
4960664157945
$130.17
(No reviews yet)
Width:
2.13 (in)
Height:
0.24 (in)
Depth:
6.69 (in)
Current Stock:
Adding to cart… The item has been added
Description
KTKB 324S, Neutral, Cut-Off Blade with a 100.00mm Maximum Cut-Off Diameter for Cut-Off Applications
Additional Information
Tool Style:
KTKB-S
Material:
Steel
Application:
Cut-Off
Hand:
Neutral
[CWN] Cutting Width Minimum (mm):
4.10
[CWX] Cutting Width Maximum (mm):
4.10
[CUTDIA] Maximum Cut-Off Diameter (Decimal Inch):
3.9370
[CUTDIA] Maximum Cut-Off Diameter (mm):
100.00
Coolant Through (Yes/No):
No
Insert Holding Method:
Self-Clamp
Unit (inch/mm):
mm
Feature 1:
Neutral KTKB Series, Cut-Off Blade
Feature 2:
Maximum Cut-Off Diameter 100.00mm
Feature 3:
Compatible with KTKTB…32 Tool Blocks and TKN4, TK…4 Inserts
ANSI Part Number:
KTKB324S
ISO Part Number:
KTKB32-4S
US Stock:
13
Worldwide Stock:
168
Compatible Inserts (Partial):
TKN4, TK…4
Old Material Number:
8801641
Wrench (for Insert Release):
LTK-5
Compatible Tool Block (Partial):
KTKTB…32
[LF] Functional Length (mm):
150.00
[CW] Cutting Width (Decimal Inch):
0.1614
[CW] Cutting Width (mm):
4.10
[CWN] Cutting Width Minimum (Decimal Inch):
0.1614
[CWX] Cutting Width Maximum (Decimal Inch):
0.1614
[LF] Functional Length (Decimal Inch):
5.9055
