LOGU 090408ERGM PR1810 Grade PVD Carbide, Indexable Milling Insert

LOGU 090408ERGM PR1810 Grade PVD Carbide, Indexable Milling Insert

SKU:
TLS00002
$31.45
(No reviews yet)
Width:
1.79 (in)
Height:
0.39 (in)
Depth:
4.15 (in)
Current Stock:
Adding to cart… The item has been added
Description
LOGU 090408ERGM PR1810 Grade PVD Carbide, 90 Degree Rectangle, Positive Rake Angle, Right-Hand Milling Insert for Roughing in (K) Gray Cast Iron, (K) Nodular Cast Iron
Additional Information
Tool Style:
LOGU
Insert Size:
0904
Chipbreaker:
ER-GM
Insert Grade:
PR1810
Material:
Carbide
Coating Process:
PVD
[S] Thickness:
0.264"
[S] Thickness (mm):
6.71
[RE] Corner Radius:
0.032"
[RE] Corner Radius (mm):
0.8
[INSL] Insert Length (Decimal Inch):
0.3500
[INSL] Insert Length (mm):
8.89
Application:
Facing|Helical Milling|High Feed|Plunging|Pocketing|Ramping|Shouldering|Slotting
Hand:
Right-Hand
Rake:
Positive
[EPSR] Insert Included Angle (Degree):
90
Primary Workpiece Material:
(K) Gray Cast Iron|(K) Nodular Cast Iron
Insert Shape:
90 Degree Rectangle
Number of Cutting Edges:
4
Cutting Range:
Medium-Roughing
Insert Holding Method:
Screw
ANSI Part Number:
LOGU090408ERGMPR1810
ISO Part Number:
LOGU090408ER-GM
Compatible Toolholder (Partial):
MA90…-09-…
Series Description (PeopleSoft):
MA90 Tangential Milling
