LOGU 120616ERGM PR1810 Grade PVD Carbide, Indexable Milling Insert
$34.95
(No reviews yet)
Write a Review
LOGU 120616ERGM PR1810 Grade PVD Carbide, Indexable Milling Insert
LOGU 120616ERGM PR1810 Grade PVD Carbide, 90 Degree Rectangle, Positive Rake Angle, Right-Hand Milling Insert for Roughing in (K) Gray Cast Iron, (K) Nodular Cast Iron
- Tool Style:
- LOGU
- Insert Size:
- 1206
- Chipbreaker:
- ER-GM
- Insert Grade:
- PR1810
- Material:
- Carbide
- Coating Process:
- PVD
- [S] Thickness:
- 0.391"
- [S] Thickness (mm):
- 9.92
- [RE] Corner Radius:
- 0.063"
- [RE] Corner Radius (mm):
- 1.6
- [INSL] Insert Length (Decimal Inch):
- 0.5228
- [INSL] Insert Length (mm):
- 13.28
- Application:
- Facing|Helical Milling|High Feed|Plunging|Pocketing|Ramping|Shouldering|Slotting
- Hand:
- Right-Hand
- Rake:
- Positive
- [EPSR] Insert Included Angle (Degree):
- 90
- Primary Workpiece Material:
- (K) Gray Cast Iron|(K) Nodular Cast Iron
- Insert Shape:
- 90 Degree Rectangle
- Number of Cutting Edges:
- 4
- Cutting Range:
- Medium-Roughing
- Insert Holding Method:
- Screw
- ANSI Part Number:
- LOGU120616ERGMPR1810
- ISO Part Number:
- LOGU120616ER-GM
- Compatible Toolholder (Partial):
- MA90…-12-…
- Series Description (PeopleSoft):
- MA90 Tangential Milling
