MECH 063R1734T (MEC Series), Helical Shell Mill
$1,092.71
(No reviews yet)
Write a Review
MECH 063R1734T (MEC Series), Helical Shell Mill
MECH 063R1734T (MEC Series), Helical Shell Mill with a 63.00mm Cutting Diameter for Shouldering, Facing Applications
- Tool Style:
- MECH
- Material:
- Steel
- Application:
- Facing|Shouldering
- Hand:
- Right-Hand
- [KAPR] Tool Entering Angle (Degree):
- 90
- [DCN] Cutting Diameter Minimum (mm):
- 63.00
- [DCX] Cutting Diameter Maximum (mm):
- 63.00
- [APMX] Maximum Depth of Cut (Decimal Inch):
- 1.7717
- [APMX] Maximum Depth of Cut (mm):
- 45.00
- Number of Inserts:
- 12
- Number of Flutes:
- 4
- [DCB] Connection Bore Diameter (mm):
- 25.40
- Coolant Through (Yes/No):
- No
- Insert Holding Method:
- Screw
- Unit (inch/mm):
- mm
- Feature 1:
- Low cutting force and reduced chattering for high-efficiency milling
- Feature 2:
- Great for various milling applications
- Feature 3:
- Compatible with: BDMT170408ER-N3, BDMT170408ER-N4 style inserts
- ANSI Part Number:
- MECH063R1734T
- ISO Part Number:
- MECH063R-17-3-4T
- US Stock:
- 0
- Worldwide Stock:
- 1
- Compatible Inserts (Partial):
- BDMT170408ER-N3, BDMT170408ER-N4
- Old Material Number:
- 8829606
- Insert Screw:
- SB-4070TRN
- Arbor Bolt:
- HH12X35
- Anti-Seize Compound:
- P-37
- Wrench (for Insert Screw):
- DTM-15
- [LF] Functional Length (mm):
- 70.00
- Product Notes 1:
- Coat Anti-Seize Compound (P-37) thinly on portion of taper and thread prior to installation.
- [DC] Cutting Diameter (Decimal Inch):
- 2.4803
- [DC] Cutting Diameter (mm):
- 63.00
- [DCN] Cutting Diameter Minimum (Decimal Inch):
- 2.4803
- [DCX] Cutting Diameter Maximum (Decimal Inch):
- 2.4803
- [DCB] Connection Bore Diameter (Decimal Inch):
- 1.0000
- [LF] Functional Length (Decimal Inch):
- 2.7559
