MECH 080R1746T (MEC Series), Helical Shell Mill

MECH 080R1746T (MEC Series), Helical Shell Mill

SKU:
THN04008
|
UPC:
4960664579358
$2,256.27
(No reviews yet)
Width:
4.65 (in)
Height:
4.49 (in)
Depth:
7.32 (in)
Current Stock:
Adding to cart… The item has been added
Description
MECH 080R1746T (MEC Series), Helical Shell Mill with a 80.00mm Cutting Diameter for Shouldering, Facing Applications
Additional Information
Tool Style:
MECH
Material:
Steel
Application:
Facing|Shouldering
Hand:
Right-Hand
[KAPR] Tool Entering Angle (Degree):
90
[DCN] Cutting Diameter Minimum (mm):
80.00
[DCX] Cutting Diameter Maximum (mm):
80.00
[APMX] Maximum Depth of Cut (Decimal Inch):
2.3228
[APMX] Maximum Depth of Cut (mm):
59.00
Number of Inserts:
24
Number of Flutes:
6
[DCB] Connection Bore Diameter (mm):
31.75
Coolant Through (Yes/No):
No
Insert Holding Method:
Screw
Unit (inch/mm):
mm
Feature 1:
Low cutting force and reduced chattering for high-efficiency milling
Feature 2:
Great for various milling applications
Feature 3:
Compatible with: BDMT170408ER-N3, BDMT170408ER-N4 style inserts
ANSI Part Number:
MECH080R1746T
ISO Part Number:
MECH080R-17-4-6T
US Stock:
0
Worldwide Stock:
0
Compatible Inserts (Partial):
BDMT170408ER-N3, BDMT170408ER-N4
Old Material Number:
8828745
Insert Screw:
SB-4070TRN
Arbor Bolt:
HH16X45
Anti-Seize Compound:
P-37
Wrench (for Insert Screw):
DTM-15
[LF] Functional Length (mm):
85.00
Product Notes 1:
Coat Anti-Seize Compound (P-37) thinly on portion of taper and thread prior to installation.
[DC] Cutting Diameter (Decimal Inch):
3.1496
[DC] Cutting Diameter (mm):
80.00
[DCN] Cutting Diameter Minimum (Decimal Inch):
3.1496
[DCX] Cutting Diameter Maximum (Decimal Inch):
3.1496
[DCB] Connection Bore Diameter (Decimal Inch):
1.2500
[LF] Functional Length (Decimal Inch):
3.3465
