MECHT 80R1746TM (MEC Series), Helical Shell Mill
$2,802.17
(No reviews yet)
Write a Review
MECHT 80R1746TM (MEC Series), Helical Shell Mill
MECH T80R1746TM (MEC Series), Coolant-Through Helical Shell Mill with a 80.00mm Cutting Diameter for Shouldering, Slotting, Facing Applications
- Tool Style:
- MECHT
- Material:
- Steel
- Application:
- Facing|Shouldering|Slotting
- Hand:
- Right-Hand
- [KAPR] Tool Entering Angle (Degree):
- 90
- [DCN] Cutting Diameter Minimum (mm):
- 80.00
- [DCX] Cutting Diameter Maximum (mm):
- 80.00
- [APMX] Maximum Depth of Cut (Decimal Inch):
- 2.3622
- [APMX] Maximum Depth of Cut (mm):
- 60.00
- Number of Inserts:
- 24
- Number of Flutes:
- 6
- [DCB] Connection Bore Diameter (mm):
- 32.00
- Coolant Through (Yes/No):
- Yes
- Insert Holding Method:
- Screw
- Unit (inch/mm):
- mm
- Feature 1:
- Unique Design for Stable Titanium Alloy Milling
- Feature 2:
- Insert combination for increased stability
- Feature 3:
- Special holder design for increased reliability
- Feature 4:
- Coolant holes for Excellent chip evacuation
- Feature 5:
- Longer Tool Life with Low-resistance JS Chipbreaker and Tough PVD Coating Technology
- ANSI Part Number:
- MECHT80R1746TM
- ISO Part Number:
- MECHT80R-17-4-6T-M
- US Stock:
- 0
- Worldwide Stock:
- 0
- Compatible Inserts (Partial):
- BDMT1704… (1st Stage), BDMT170408… (2nd Stage and Above)
- Old Material Number:
- 8864955
- Insert Screw:
- SB-4070TRN
- Arbor Bolt:
- HH16X65
- Anti-Seize Compound:
- P-37
- Wrench (for Insert Screw):
- DTM-15
- [LF] Functional Length (mm):
- 80.00
- Product Notes 1:
- Coat Anti-Seize Compound (P-37) thinly on portion of taper and thread prior to installation.
- [DC] Cutting Diameter (Decimal Inch):
- 3.1496
- [DC] Cutting Diameter (mm):
- 80.00
- [DCN] Cutting Diameter Minimum (Decimal Inch):
- 3.1496
- [DCX] Cutting Diameter Maximum (Decimal Inch):
- 3.1496
- [DCB] Connection Bore Diameter (Decimal Inch):
- 1.2598
- [LF] Functional Length (Decimal Inch):
- 3.1496
