MEW 25M12103T, Modular Head End Mill
MEW 25M12103T 90 Degree Lead, 3 Flute, Coolant-Through Modular Head End Mill with a 25.00mm Cutting Diameter for Shouldering, Slotting, Facing, Plunging Applications
- Tool Style:
- MEW
- Material:
- Steel
- Application:
- Facing|Plunging|Shouldering|Slotting
- Hand:
- Right-Hand
- [KAPR] Tool Entering Angle (Degree):
- 90
- [DCN] Cutting Diameter Minimum (mm):
- 25.00
- [DCX] Cutting Diameter Maximum (mm):
- 25.00
- [APMX] Maximum Depth of Cut (Decimal Inch):
- 0.3937
- [APMX] Maximum Depth of Cut (mm):
- 10.00
- Number of Inserts:
- 3
- Number of Flutes:
- 3
- [H] Shank Height (mm):
- 19.00
- Shank Type:
- Modular Connection
- Weldon Flat:
- No
- [DCON] Connection Diameter (mm):
- 12.50
- [DCSFMS] Contact Surface Diameter Machine Side (mm):
- 23.00
- Coolant Through (Yes/No):
- Yes
- Insert Holding Method:
- Screw
- Unit (inch/mm):
- mm
- Feature 1:
- 90 degree milling with economical, double-sided 4-edge inserts
- Feature 2:
- Now including DLC coated inserts for aluminum machining
- Feature 3:
- Improved toolholder durability and insert installation accuracy
- Feature 4:
- Compatible with (3) LOMU1004…, LOGT1004… style inserts
- ANSI Part Number:
- MEW25M12103T
- ISO Part Number:
- MEW25-M12-10-3T
- US Stock:
- 5
- Worldwide Stock:
- 15
- Compatible Inserts (Partial):
- LOMU1004…, LOGT1004…
- Old Material Number:
- 8837958
- Insert Screw:
- SB-3065TRP
- Anti-Seize Compound:
- P-37
- Wrench (for Insert Screw):
- DTPM-8
- Tightening Torque:
- 1.2 Nm (for Insert Screw)
- [LF] Functional Length (mm):
- 35.00
- Product Notes 1:
- Coat Anti-Seize Compound (P-37) thinly on portion of taper and thread prior to installation.
- [DC] Cutting Diameter (Decimal Inch):
- 0.9843
- [DC] Cutting Diameter (mm):
- 25.00
- [DCN] Cutting Diameter Minimum (Decimal Inch):
- 0.9843
- [DCX] Cutting Diameter Maximum (Decimal Inch):
- 0.9843
- [H] Shank Height (Decimal Inch):
- 0.7480
- [DCON] Connection Diameter (Decimal Inch):
- 0.4921
- [DCSFMS] Contact Surface Diameter Machine Side (Decimal Inch):
- 0.9055
- [LF] Functional Length (Decimal Inch):
- 1.3780
- [OAL] Overall Length (mm):
- 57.00
- [OAL] Overall Length (Decimal Inch):
- 2.2441
