MFPN 66032RS322TG Standard Length Shank, 66 Degree End Mill
$386.66
(No reviews yet)
Write a Review
MFPN 66032RS322TG Standard Length Shank, 66 Degree End Mill
MFPN 66032RS322TG Standard Length, Cylindrical Shank, 2 Flute, 66 Degree End Mill with a 32.00mm Cutting Diameter for Facing Applications
- Tool Style:
- MFPN
- Material:
- Steel
- Application:
- Facing
- Hand:
- Right-Hand
- [KAPR] Tool Entering Angle (Degree):
- 66
- [DCN] Cutting Diameter Minimum (mm):
- 32.00
- [DCX] Cutting Diameter Maximum (mm):
- 39.50
- [APMX] Maximum Depth of Cut (Decimal Inch):
- 0.1969
- [APMX] Maximum Depth of Cut (mm):
- 5.00
- Number of Inserts:
- 2
- Number of Flutes:
- 2
- Shank Type:
- Standard Length
- Weldon Flat:
- No
- [DCON] Connection Diameter (mm):
- 32.00
- Coolant Through (Yes/No):
- No
- Insert Holding Method:
- Screw
- Unit (inch/mm):
- mm
- Feature 1:
- High Efficiency Milling with a 24 Degree Lead Angle
- Feature 2:
- Economical Double-sided 10-edge Inserts
- Feature 3:
- Reduces chattering with Low Cutting Force Design
- Feature 4:
- Reduces Cutting Costs when Machining Auto Parts and Other General Purpose Machining Applications
- Feature 5:
- Compatible with PNMU0905XNER-GM, PNMU0905XNER-SM, PNMU0905XNER-GH Inserts
- ANSI Part Number:
- MFPN66032RS322TG
- ISO Part Number:
- MFPN66032R-S32-2T-G
- US Stock:
- 0
- Worldwide Stock:
- 0
- Compatible Inserts (Partial):
- PNMU0905XNER-GM, PNMU0905XNER-SM, PNMU0905XNER-GH
- Old Material Number:
- 8858702
- Insert Screw:
- SB-4090TRP
- Anti-Seize Compound:
- P-37
- Wrench (for Insert Screw):
- DTPM-15
- Tightening Torque:
- 3.5 Nm (for Insert Screw)
- [LF] Functional Length (mm):
- 110.00
- [LH] Head Length (mm):
- 30.00
- Product Notes 1:
- Coat Anti-Seize Compound (P-37) thinly on portion of taper and thread prior to installation.
- [DC] Cutting Diameter (Decimal Inch):
- 1.2598 - 1.5551
- [DC] Cutting Diameter (mm):
- 32.00 - 39.50
- [DCN] Cutting Diameter Minimum (Decimal Inch):
- 1.2598
- [DCX] Cutting Diameter Maximum (Decimal Inch):
- 1.5551
- [DCON] Connection Diameter (Decimal Inch):
- 1.2598
- [LF] Functional Length (Decimal Inch):
- 4.3307
- [LH] Head Length (Decimal Inch):
- 1.1811
