MFSE 45160R7TM Metric Bore Diameter, 45 Degree Face Mill
$1,384.32
(No reviews yet)
Write a Review
MFSE 45160R7TM Metric Bore Diameter, 45 Degree Face Mill
MFSE 45160R7TM Metric Bore Diameter, Coarse Pitch, 7 Flute, 45 Degree Face Mill with a 160.00mm Cutting Diameter for Facing, Chamfering Applications
- Tool Style:
- MFSE
- Application:
- Chamfering|Facing
- Hand:
- Right-Hand
- [KAPR] Tool Entering Angle (Degree):
- 45
- [DCN] Cutting Diameter Minimum (mm):
- 160.00
- [DCX] Cutting Diameter Maximum (mm):
- 168.70
- Number of Inserts:
- 7
- Number of Flutes:
- 7
- Bore Diameter (Inch/Metric):
- Metric
- [DCB] Connection Bore Diameter (mm):
- 40.00
- [DCSFMS] Contact Surface Diameter Machine Side (mm):
- 110.00
- Coolant Through (Yes/No):
- No
- Unit (inch/mm):
- mm
- Feature 1:
- 45 Degree Lead Angle Finishing Face Mill
- Feature 2:
- Delivers high quality surface finishes
- Feature 3:
- Longer tool life by reducing front edge runout
- ANSI Part Number:
- MFSE45160R7TM
- ISO Part Number:
- MFSE45160R-7T-M
- US Stock:
- 0
- Worldwide Stock:
- 1
- Material:
- Steel
- [APMX] Maximum Depth of Cut (Decimal Inch):
- 0.2362
- [APMX] Maximum Depth of Cut (mm):
- 6.00
- Cutter Pitch:
- Coarse Pitch
- Insert Holding Method:
- Screw
- Compatible Inserts (Partial):
- SEET13T3AGSN-GL, SEET13T3AGSN-SL, SEET13T3AGFN-AL
- Old Material Number:
- 8867146
- Insert Screw:
- SB-35120TRP
- Shim:
- MFSE-105
- Shim Screw:
- SPW-5035
- Anti-Seize Compound:
- P-37
- Wrench (for Insert Screw):
- DTPM-15
- Wrench (for Shim Screw):
- LW-3.5
- Tightening Torque:
- 4 Nm (for Insert Screw), 5 Nm (for Shim Screw)
- [LF] Functional Length (mm):
- 63.00
- Product Notes 1:
- Coat Anti-Seize Compound (P-37) thinly on portion of taper and thread prior to installation.
- [DC] Cutting Diameter (Decimal Inch):
- 6.2992 - 6.6417
- [DC] Cutting Diameter (mm):
- 160.00 - 168.70
- [DCN] Cutting Diameter Minimum (Decimal Inch):
- 6.2992
- [DCX] Cutting Diameter Maximum (Decimal Inch):
- 6.6417
- [DCB] Connection Bore Diameter (Decimal Inch):
- 1.5748
- [DCSFMS] Contact Surface Diameter Machine Side (Decimal Inch):
- 4.3307
- [LF] Functional Length (Decimal Inch):
- 2.4803
