MRW 1250W125123T RAD-8 Series, Standard Length Shank, Radius End Mill
$430.59
(No reviews yet)
Write a Review
MRW 1250W125123T RAD-8 Series, Standard Length Shank, Radius End Mill
MRW 1250W125123T RAD-8 Series, 3 Flute, Standard Length Shank, Radius End Mill with a 1.2500" Cutting Diameter for Shouldering, Facing, Contour Line Milling Applications
- Tool Style:
- MRW
- Material:
- Steel
- Application:
- Contouring|Facing|Plunging|Profiling|Shouldering
- Hand:
- Right-Hand
- [KAPR] Tool Entering Angle (Degree):
- n/a
- [DCN] Cutting Diameter Minimum (mm):
- 31.75
- [DCX] Cutting Diameter Maximum (mm):
- 31.75
- [APMX] Maximum Depth of Cut (Decimal Inch):
- 0.2362
- [APMX] Maximum Depth of Cut (mm):
- 6.00
- Number of Inserts:
- 3
- Number of Flutes:
- 3
- Shank Type:
- Standard Length
- Weldon Flat:
- Yes
- [DCON] Connection Diameter (mm):
- 31.75
- Coolant Through (Yes/No):
- Yes
- Insert Holding Method:
- Screw
- Unit (inch/mm):
- inch
- Feature 1:
- Economical double-sided 8-edge inserts
- Feature 2:
- Combined sharpness and strength with improved edge strength due to obtuse edge shape
- Feature 3:
- Lower cutting forces equivalent to positive inserts
- Feature 4:
- Flat lock structure prevents insert rotation during machining to provide stable cutting
- Feature 5:
- CA6535 and PR1535 insert grades available for difficult-to-cut material
- ANSI Part Number:
- MRW1250W125123T
- ISO Part Number:
- MRW1250-W125-12-3T
- US Stock:
- 9
- Worldwide Stock:
- 0
- Compatible Inserts (Partial):
- ROMU1204M0ER-GM, ROMU1204M0ER-SM, ROMU1204M0ER-GH
- Old Material Number:
- 8838341
- Insert Screw:
- SB-4085TRP
- Anti-Seize Compound:
- P-37
- Wrench (for Insert Screw):
- DTPM-15
- Tightening Torque:
- 3.5 Nm (for Insert Screw)
- [LF] Functional Length (mm):
- 99.59
- [LH] Head Length (mm):
- 40.00
- Product Notes 1:
- Coat Anti-Seize Compound (P-37) thinly on portion of taper and thread prior to installation.
- [DC] Cutting Diameter (Decimal Inch):
- 1.2500
- [DC] Cutting Diameter (mm):
- 31.75
- [DCN] Cutting Diameter Minimum (Decimal Inch):
- 1.2500
- [DCX] Cutting Diameter Maximum (Decimal Inch):
- 1.2500
- [DCON] Connection Diameter (Decimal Inch):
- 1.2500
- [LF] Functional Length (Decimal Inch):
- 3.9209
- [LH] Head Length (Decimal Inch):
- 1.5748
