PKM 48N030PM PR1535 Grade PVD Carbide, Indexable Cut-Off Insert
$26.50
(No reviews yet)
Write a Review
PKM 48N030PM PR1535 Grade PVD Carbide, Indexable Cut-Off Insert
PKM 48N030PM PR1535 Grade PVD Carbide, 4.80mm Cutting Width, Neutral Cut-Off Insert for Light Interruption and Medium-Roughing in (P) Carbon/Alloy Steel and (M) Stainless Steel Material Applications
- Tool Style:
- PKM
- Insert Size:
- 48
- Chipbreaker:
- PM
- Insert Grade:
- PR1535
- Material:
- Carbide
- Coating Process:
- PVD
- [RE] Corner Radius (mm):
- 0.30
- Application:
- Cut-Off
- Hand:
- Neutral
- Rake:
- Positive
- [CWN] Cutting Width Minimum (mm):
- 4.80
- [CWX] Cutting Width Maximum (mm):
- 4.80
- Primary Workpiece Material:
- (M) Stainless Steel
- Full Radius:
- No
- Number of Cutting Edges:
- 1
- Usage Classification:
- Light Interruption
- Cutting Range:
- Medium-Roughing
- Insert Holding Method:
- Self-Clamp
- Unit (inch/mm):
- inch
- Feature 1:
- Insert for Cut-Off
- Feature 2:
- General Purpose
- Feature 3:
- 1 Cutting Edge
- Feature 4:
- Nano thin multi-layer coating MEGACOAT NANO for superior wear resistance and high oxidation resistance
- Feature 5:
- Application: PVD for (P) Carbon/Alloy Steel and (M) Stainless Steel
- ANSI Part Number:
- PKM48N030PMPR1535
- ISO Part Number:
- PKM48N-030PM
- US Stock:
- 20
- Worldwide Stock:
- 90
- Old Material Number:
- 8867799
- Compatible Toolholder (Partial):
- KPKB26-5, KPKB26-5JCT, KPKB32-5, KPKB32-5JCT, KPKHL16-5, KPKHL2525M-5, KPKHR16-5, KPKHR2525M-5
- [RE] Corner Radius:
- 0.012"
- [CW] Cutting Width (Decimal Inch):
- 0.1890
- [CW] Cutting Width (mm):
- 4.80
- [CWN] Cutting Width Minimum (Decimal Inch):
- 0.1890
- [CWX] Cutting Width Maximum (Decimal Inch):
- 0.1890
