PKM 60N040PH PR1625 Grade PVD Carbide, Indexable Cut-Off Insert
$28.12
(No reviews yet)
Write a Review
PKM 60N040PH PR1625 Grade PVD Carbide, Indexable Cut-Off Insert
PKM 60N040PH PR1625 Grade PVD Carbide, 6.00mm Cutting Width, Neutral Cut-Off Insert for Light Interruption and Medium-Roughing in (P) Carbon/Alloy Steel and (M) Stainless Steel Material Applications
- Tool Style:
- PKM
- Insert Size:
- 60
- Chipbreaker:
- PM
- Insert Grade:
- PR1625
- Material:
- Carbide
- Coating Process:
- PVD
- [RE] Corner Radius (mm):
- 0.40
- Application:
- Cut-Off
- Hand:
- Neutral
- Rake:
- Positive
- [CWN] Cutting Width Minimum (mm):
- 6.00
- [CWX] Cutting Width Maximum (mm):
- 6.00
- Primary Workpiece Material:
- (P) Carbon/Alloy Steel
- Full Radius:
- No
- Number of Cutting Edges:
- 1
- Usage Classification:
- Light Interruption
- Cutting Range:
- Medium-Roughing
- Insert Holding Method:
- Self-Clamp
- Unit (inch/mm):
- inch
- Feature 1:
- Insert for Cut-Off
- Feature 2:
- Tough Edge
- Feature 3:
- 1 Cutting Edge
- Feature 4:
- Nano thin multi-layer coating MEGACOAT NANO for superior wear resistance and high oxidation resistance
- Feature 5:
- Application: PVD for (P) Carbon/Alloy Steel and (M) Stainless Steel
- ANSI Part Number:
- PKM60N040PHPR1625
- ISO Part Number:
- PKM60N-040PH
- US Stock:
- 20
- Worldwide Stock:
- 30
- Old Material Number:
- 8867816
- Compatible Toolholder (Partial):
- KPKB32-6, KPKB32-6JCT
- [RE] Corner Radius:
- 1/64"
- [CW] Cutting Width (Decimal Inch):
- 0.2362
- [CW] Cutting Width (mm):
- 6.00
- [CWN] Cutting Width Minimum (Decimal Inch):
- 0.2362
- [CWX] Cutting Width Maximum (Decimal Inch):
- 0.2362
