PNEU 1205ANERW PR1510 Grade PVD Carbide, Indexable Milling Insert
$39.30
(No reviews yet)
Write a Review
PNEU 1205ANERW PR1510 Grade PVD Carbide, Indexable Milling Insert
PNEU 1205ANERW PR1510 Grade PVD Carbide, Pentagon, Negative Rake Angle, Right-Hand Milling Insert for Roughing in (K) Gray Cast Iron, (K) Nodular Cast Iron
- Tool Style:
- PNEU
- Insert Size:
- 1205
- Chipbreaker:
- ANER-W
- Insert Grade:
- PR1510
- Material:
- Carbide
- Coating Process:
- PVD
- [S] Thickness (mm):
- 5.56
- [INSL] Insert Length (mm):
- 17.85
- Application:
- Chamfering|Facing
- Hand:
- Right-Hand
- Rake:
- Negative
- [EPSR] Insert Included Angle (Degree):
- n/a
- Primary Workpiece Material:
- (K) Gray Cast Iron|(K) Nodular Cast Iron
- Insert Shape:
- Pentagon
- Number of Cutting Edges:
- 2
- Cutting Range:
- Roughing
- Insert Holding Method:
- Screw
- Feature 1:
- Insert for Facing, Chamfering
- Feature 2:
- Honed Edge / Wiper Edge / 2-Edge with 2 Cutting Edges
- Feature 3:
- MEGACOAT NANO coating technology
- Feature 4:
- Nano thin multi-layer coating performs with wear resistance and high oxidation resistance
- Feature 5:
- Application: For gray and nodular cast iron, stable wear resistance and toughness
- ANSI Part Number:
- PNEU1205ANERWPR1510
- ISO Part Number:
- PNEU1205ANER-W
- US Stock:
- 270
- Worldwide Stock:
- 0
- Old Material Number:
- 8837831
- Compatible Toolholder (Partial):
- MFPN45…R-…
- [S] Thickness:
- 7/32"
- [INSL] Insert Length (Decimal Inch):
- 0.7028
- Series Description (PeopleSoft):
- MFPN Milling
- Series Description:
- MFPN Milling
