PNMG 1106XNENGM PR1525 Grade PVD Carbide, Indexable Milling Insert

PNMG 1106XNENGM PR1525 Grade PVD Carbide, Indexable Milling Insert

SKU:
TLB05200
|
UPC:
4960664732906
$24.38
(No reviews yet)
Width:
2.44 (in)
Height:
0.55 (in)
Depth:
5.12 (in)
Current Stock:
Adding to cart… The item has been added
Description
PNMG 1106XNENGM PR1525 Grade PVD Carbide, Pentagon, Negative Rake Angle, Neutral Milling Insert for Finishing in (K) Gray Cast Iron, (K) Nodular Cast Iron
Additional Information
Tool Style:
PNMG
Insert Size:
1106
Chipbreaker:
XNEN-GM
Insert Grade:
PR1525
Material:
Carbide
Coating Process:
PVD
[S] Thickness (mm):
6.35
[INSL] Insert Length (mm):
17.23
Application:
Chamfering|Facing
Hand:
Neutral
Rake:
Negative
[EPSR] Insert Included Angle (Degree):
n/a
Primary Workpiece Material:
(K) Gray Cast Iron|(K) Nodular Cast Iron
Insert Shape:
Pentagon
Number of Cutting Edges:
10
Cutting Range:
Finishing
Insert Holding Method:
Screw
Feature 1:
Insert for Facing, Chamfering
Feature 2:
Honed Edge / General Purpose with 10 Cutting Edges
Feature 3:
MEGACOAT NANO coating technology
Feature 4:
Nano thin multi-layer coating performs with wear resistance and high oxidation resistance
Feature 5:
Application: Stable and long tool life milling of steel and stainless steel
ANSI Part Number:
PNMG1106XNENGMPR1525
ISO Part Number:
PNMG1106XNEN-GM
US Stock:
190
Worldwide Stock:
410
Old Material Number:
8842535
Compatible Toolholder (Partial):
MFK…-11-…
[S] Thickness:
1/4"
[INSL] Insert Length (Decimal Inch):
0.6784
