S12FSCLCL06 External Sleeve, Indexable Turning Round Shank Toolholder
$267.28
(No reviews yet)
Write a Review
S12FSCLCL06 External Sleeve, Indexable Turning Round Shank Toolholder
S12FSCLCL06, Left-Hand, Positive Rake, 95 Degree Lead Angle, Indexable Round Shank Turning Holder for Swiss External Turning, Facing
- Tool Style:
- S…SCLC06
- Material:
- Steel
- Application:
- External Turning|Facing|Small Parts Machining
- Hand:
- Left-Hand
- Rake:
- Positive
- [KAPR] Tool Entering Angle (Degree):
- 95
- Insert Shape:
- 80 Degree Diamond
- [H] Shank Height (mm):
- 11.00
- [DCON] Connection Diameter (mm):
- 12.00
- Coolant Through (Yes/No):
- No
- Insert Holding Method:
- Screw
- Unit (inch/mm):
- mm
- Feature 1:
- Left-Hand Toolholder
- Feature 2:
- Application: Swiss External Turning, Facing
- Feature 3:
- Screw Clamp Insert Holding Design
- Feature 4:
- Compatible with Right-Hand CCGT215…, CCMT215…, CCGW215…, CCMW215… Inserts
- Feature 5:
- Round Shank
- ANSI Part Number:
- S12FSCLCL06
- ISO Part Number:
- S12F-SCLCL06
- Compatible Inserts (Partial):
- CCGT215…, CCMT215…, CCGW215…, CCMW215…
- Old Material Number:
- 8821015
- Insert Screw:
- SB-2560TR
- Wrench (for Insert Screw):
- FT-8
- Product Notes:
- Right-hand Insert for Left-hand Toolholder
- [LF] Functional Length (mm):
- 80.00
- [H] Shank Height (Decimal Inch):
- 0.4331
- [DCON] Connection Diameter (Decimal Inch):
- 0.4724
- [LF] Functional Length (Decimal Inch):
- 3.1496
- Series Description (PeopleSoft):
- Swiss Turning Holder
- Series Description:
- Swiss Turning Holder
