S16FSCLCL06 External Sleeve, Indexable Turning Round Shank Toolholder

S16FSCLCL06 External Sleeve, Indexable Turning Round Shank Toolholder

SKU:
THC09013
$267.28
(No reviews yet)
Width:
1.38 (in)
Height:
1.14 (in)
Depth:
5.91 (in)
Current Stock:
Adding to cart… The item has been added
Description
S16FSCLCL06, Left-Hand, Positive Rake, 95 Degree Lead Angle, Indexable Round Shank Turning Holder for Swiss External Turning, Facing
Additional Information
Tool Style:
S…SCLC06
Material:
Steel
Application:
External Turning|Facing|Small Parts Machining
Hand:
Left-Hand
Rake:
Positive
[KAPR] Tool Entering Angle (Degree):
95
Insert Shape:
80 Degree Diamond
[H] Shank Height (mm):
15.00
[DCON] Connection Diameter (mm):
16.00
Coolant Through (Yes/No):
No
Insert Holding Method:
Screw
Unit (inch/mm):
mm
Feature 1:
Left-Hand Toolholder
Feature 2:
Application: Swiss External Turning, Facing
Feature 3:
Screw Clamp Insert Holding Design
Feature 4:
Compatible with Right-Hand CCGT215…, CCMT215…, CCGW215…, CCMW215… Inserts
Feature 5:
Round Shank
ANSI Part Number:
S16FSCLCL06
ISO Part Number:
S16F-SCLCL06
Compatible Inserts (Partial):
CCGT215…, CCMT215…, CCGW215…, CCMW215…
Old Material Number:
8821024
Insert Screw:
SB-2570TR
Wrench (for Insert Screw):
FT-8
Product Notes:
Right-hand Insert for Left-hand Toolholder
[LF] Functional Length (mm):
85.00
[H] Shank Height (Decimal Inch):
0.5906
[DCON] Connection Diameter (Decimal Inch):
0.6299
[LF] Functional Length (Decimal Inch):
3.3465
Series Description (PeopleSoft):
Swiss Turning Holder
Series Description:
Swiss Turning Holder
