S19GSDUCL11 External Sleeve, Indexable Turning Round Shank Toolholder

S19GSDUCL11 External Sleeve, Indexable Turning Round Shank Toolholder

SKU:
THC09068
|
UPC:
4960664409853
$300.67
(No reviews yet)
Width:
1.38 (in)
Height:
1.14 (in)
Depth:
5.91 (in)
Current Stock:
Adding to cart… The item has been added
Description
S19GSDUCL11, Left-Hand, Positive Rake, 93 Degree Lead Angle, Indexable Round Shank Turning Holder for Swiss External Turning, Facing
Additional Information
Tool Style:
S…SDUC11
Material:
Steel
Application:
External Turning|Facing|Small Parts Machining
Hand:
Left-Hand
Rake:
Positive
[KAPR] Tool Entering Angle (Degree):
93
Insert Shape:
55 Degree Diamond
[H] Shank Height (mm):
17.00
[DCON] Connection Diameter (mm):
19.05
Coolant Through (Yes/No):
No
Insert Holding Method:
Screw
Unit (inch/mm):
inch
Feature 1:
Left-Hand Toolholder
Feature 2:
Application: Swiss External Turning, Facing
Feature 3:
Screw Clamp Insert Holding Design
Feature 4:
Compatible with Right-Hand DCGT325…, DCMX325…, DCMT325…, DCET325…, DCGW325…, DCMW325… Inserts
Feature 5:
Round Shank
ANSI Part Number:
S19GSDUCL11
ISO Part Number:
S19G-SDUCL11
US Stock:
0
Worldwide Stock:
56
Compatible Inserts (Partial):
DCGT325…, DCMX325…, DCMT325…, DCET325…, DCGW325…, DCMW325…
Old Material Number:
8813226
Insert Screw:
SB-4085TR
Wrench (for Insert Screw):
FT-15
[LF] Functional Length (mm):
90.00
Product Notes:
Right-hand Insert for Left-hand Toolholder
[H] Shank Height (Decimal Inch):
0.6693
[DCON] Connection Diameter (Decimal Inch):
0.7500
[LF] Functional Length (Decimal Inch):
3.5433
