S25HSVNR12 Right-Hand, Micro Boring Bar Toolholder

S25HSVNR12 Right-Hand, Micro Boring Bar Toolholder

SKU:
THC07308
|
UPC:
4960664227808
$294.39
(No reviews yet)
Width:
1.38 (in)
Height:
1.14 (in)
Depth:
7.09 (in)
Current Stock:
Adding to cart… The item has been added
Description
S25HSVNR12 Right-Hand Micro Bar Toolholder with a 1.0000" Shank Diameter for Micro Boring, Micro Grooving, Micro Face Grooving, Micro Threading Applications
Additional Information
Tool Style:
S-SVNR
Material:
Steel
Application:
Micro Boring|Micro Internal Face Grooving|Micro Internal Grooving|Micro Internal Threading
Hand:
Right-Hand
[H] Shank Height (mm):
23.00
[DCON] Connection Diameter (mm):
25.40
Coolant Through (Yes/No):
No
Insert Holding Method:
Screw
Unit (inch/mm):
inch
Feature 1:
Swiss IQ Bar
Feature 2:
Round standard shank toolholder with side stopper
Feature 3:
Great for general horizontal and front-loading gang types
Feature 4:
For VNBR…, VNBTR…, VNGR…, VNFGR…, VNTR… style inserts
ANSI Part Number:
S25HSVNR12
ISO Part Number:
S25H-SVNR12
US Stock:
0
Worldwide Stock:
0
Old Material Number:
8607527
Compatible Bars (Partial):
VNBR…, VNBTR…, VNGR…, VNFGR…, VNTR…
[LF] Functional Length (mm):
100.00
[LH] Head Length (mm):
24.00
[H] Shank Height (Decimal Inch):
0.9055
[DCON] Connection Diameter (Decimal Inch):
1.0000
[LF] Functional Length (Decimal Inch):
3.9370
[LH] Head Length (Decimal Inch):
0.9449
