S40TCELNR1350 Right-Hand, Negative Rake, Boring Bar
$467.69
(No reviews yet)
Write a Review
S40TCELNR1350 Right-Hand, Negative Rake, Boring Bar
S40TCELNR1350 Right-Hand, Negative Rake, Ceramic Tool Boring Bar with 97.5 Degree Lead Angle and 50.00mm Minimum Bore Dia.
- Tool Style:
- S...CELN
- Material:
- Steel
- Bar Type:
- Steel Shank
- Application:
- Boring|Internal Facing
- Hand:
- Right-Hand
- Rake:
- Negative
- [KAPR] Tool Entering Angle (Degree):
- 97.5
- Insert Shape:
- 75 Degree Diamond
- [DMIN] Minimum Bore Diameter (mm):
- 50.00
- [H] Shank Height (mm):
- 37.00
- [DCON] Connection Diameter (mm):
- 40.00
- Coolant Through (Yes/No):
- No
- Insert Holding Method:
- Top Clamp
- Unit (inch/mm):
- mm
- Feature 1:
- High rigidity indexable boring bars for notched ceramic inserts
- Feature 2:
- 0 (Axial), -12 (Radial) Rake Angle Ceramic Tool Boring Bar
- Feature 3:
- Great for Boring, Internal Facing Applications
- Feature 4:
- Compatible with Left-Hand ENG45… Inserts
- ANSI Part Number:
- S40TCELNR1350
- ISO Part Number:
- S40T-CELNR13-50
- US Stock:
- 0
- Worldwide Stock:
- 0
- Compatible Inserts (Partial):
- ENG45…
- Old Material Number:
- 8805388
- Clamp Set:
- CE-010
- Shim:
- SP-341P
- Shim Screw:
- M3X8
- Chipbreaker Attachment:
- CB-16
- Wrench (for Clamp Screw):
- LW-4
- [LF] Functional Length (mm):
- 300.00
- [LH] Head Length (mm):
- 32.00
- Product Notes:
- Left-hand Insert for Right-hand Toolholder
- [DMIN] Minimum Bore Diameter (Decimal Inch):
- 1.9685
- [H] Shank Height (Decimal Inch):
- 1.4567
- [DCON] Connection Diameter (Decimal Inch):
- 1.5748
- [LF] Functional Length (Decimal Inch):
- 11.8110
- [LH] Head Length (Decimal Inch):
- 1.2598
