S40TPTUNL1650 Left-Hand, Negative Rake, Boring Bar

S40TPTUNL1650 Left-Hand, Negative Rake, Boring Bar

SKU:
THC08061
$467.69
(No reviews yet)
Width:
2.36 (in)
Height:
2.36 (in)
Depth:
25.20 (in)
Current Stock:
Adding to cart… The item has been added
Description
S40TPTUNL1650 Left-Hand, Negative Rake, General Purpose Boring Bar with 93 Degree Lead Angle and 50.00mm Minimum Bore Dia.
Additional Information
Tool Style:
S...PTUN16
Material:
Steel
Bar Type:
Steel Shank
Application:
Boring
Hand:
Left-Hand
Rake:
Negative
[KAPR] Tool Entering Angle (Degree):
93
Insert Shape:
60 Degree Triangle
[DMIN] Minimum Bore Diameter (mm):
50.00
[H] Shank Height (mm):
37.00
[DCON] Connection Diameter (mm):
40.00
Coolant Through (Yes/No):
No
Insert Holding Method:
Lever Lock / Lock Pin
Unit (inch/mm):
mm
Feature 1:
~6 (Axial), -11 (Radial) Rake Angle General Purpose Boring Bar
Feature 2:
Great for Boring Applications
Feature 3:
Compatible with Right-Hand TNMG33…, TNGG33…, TNGA33…, TNMM33… Inserts
ANSI Part Number:
S40TPTUNL1650
ISO Part Number:
S40T-PTUNL16-50
Compatible Inserts (Partial):
TNMG33…, TNGG33…, TNGA33…, TNMM33…
Old Material Number:
8813361
Shim:
LT-32N*
Shim Pin:
LSP-1
Punch:
PC-1
Lever:
LL-1N
Lock Screw:
LS-1N
Wrench (for Lock Screw):
FH-2.5
Product Notes:
Right-hand Insert for Left-hand Toolholder
Product Notes 1:
*Use shim LT-32N-20 (sold separately) when using inserts with a corner-R (RE) greater than 1/16" to prevent workpiece and shim from interfering with each other.
[LF] Functional Length (mm):
300.00
[LH] Head Length (mm):
60.00
[DMIN] Minimum Bore Diameter (Decimal Inch):
1.9685
[H] Shank Height (Decimal Inch):
1.4567
[DCON] Connection Diameter (Decimal Inch):
1.5748
[LF] Functional Length (Decimal Inch):
11.8110
[LH] Head Length (Decimal Inch):
2.3622
