SABWR 1023JXF, Indexable Turning Toolholder

SABWR 1023JXF, Indexable Turning Toolholder

SKU:
THC89747
|
UPC:
4960664647019
$160.36
(No reviews yet)
Width:
1.38 (in)
Height:
1.14 (in)
Depth:
5.91 (in)
Current Stock:
Adding to cart… The item has been added
Description
SABWR 1023JXF, Right-Hand, Positive Rake, 40 Degree Lead Angle, Indexable Turning Toolholder for Swiss, Back Turning Applications
Additional Information
Tool Style:
SABW
Material:
Steel
Application:
Back Turning|Small Parts Machining
Hand:
Right-Hand
Rake:
Positive
[KAPR] Tool Entering Angle (Degree):
40
[CWN] Cutting Width Minimum (mm):
7.00
[CWX] Cutting Width Maximum (mm):
7.00
Insert Shape:
Irregular
[H] Shank Height (mm):
15.88
[B] Shank Width (mm):
15.875
Coolant Through (Yes/No):
No
Insert Holding Method:
Screw
Unit (inch/mm):
inch
Feature 1:
Right-Hand Toolholder
Feature 2:
Application: Swiss, Back Turning
Feature 3:
Screw Clamp Insert Holding Design
Feature 4:
Compatible with Right-Hand ABW23R… Style Inserts
Feature 5:
Simple Mechanism with Fewer Parts for Finishing to Medium Machining
ANSI Part Number:
SABWR1023JXF
ISO Part Number:
SABWR10-23JXF
US Stock:
2
Worldwide Stock:
0
Compatible Inserts (Partial):
ABW23R…
Old Material Number:
8835482
Insert Screw:
SB-3080TR
Wrench (for Insert Screw):
FT-10
[LF] Functional Length (mm):
120.65
[CW] Cutting Width (Decimal Inch):
0.2756
[CW] Cutting Width (mm):
7.00
[CWN] Cutting Width Minimum (Decimal Inch):
0.2756
[CWX] Cutting Width Maximum (Decimal Inch):
0.2756
[H] Shank Height (Decimal Inch):
0.6252
[B] Shank Width (Decimal Inch):
0.6250
[LF] Functional Length (Decimal Inch):
4.7500
Series Description (PeopleSoft):
Back Turning Toolholder
