SCLCL 62JXFF, Indexable Turning Toolholder

SCLCL 62JXFF, Indexable Turning Toolholder

SKU:
THC89663
$83.96
(No reviews yet)
Width:
1.38 (in)
Height:
1.14 (in)
Depth:
5.91 (in)
Current Stock:
Adding to cart… The item has been added
Description
SCLCL 62JXFF, Left-Hand, Positive Rake, 95 Degree Lead Angle, Indexable Turning Toolholder for Swiss, External Turning, Facing Applications
Additional Information
Tool Style:
SCLC-FF
Material:
Steel
Application:
External Turning|Facing|Small Parts Machining
Hand:
Left-Hand
Rake:
Positive
[KAPR] Tool Entering Angle (Degree):
95
Insert Shape:
80 Degree Diamond
[H] Shank Height (Decimal Inch):
0.3752
[H] Shank Height (mm):
9.53
[B] Shank Width (Decimal Inch):
0.3750
[B] Shank Width (mm):
9.525
Coolant Through (Yes/No):
No
Insert Holding Method:
Screw
Unit (inch/mm):
inch
Feature 1:
Left-Hand Toolholder
Feature 2:
Application: Swiss, External Turning, Facing
Feature 3:
Screw Clamp Insert Holding Design
Feature 4:
Compatible with Left-Hand CCGT215…, CCMT215…, CCGW215…, CCMW215… Style Inserts
Feature 5:
Simple Mechanism with Fewer Parts for Finishing to Medium Machining
ANSI Part Number:
SCLCL62JXFF
ISO Part Number:
SCLCL6-2JXFF
Compatible Inserts (Partial):
CCGT215…, CCMT215…, CCGW215…, CCMW215…
Old Material Number:
8835644
Insert Screw:
SB-2570TR
Wrench (for Insert Screw):
FT-8
[LF] Functional Length (Decimal Inch):
4.7500
[LF] Functional Length (mm):
120.65
