SFL 1502C, Face Grooving Blade

SFL 1502C, Face Grooving Blade

SKU:
THC05085
|
UPC:
4960664011131
$63.18
(No reviews yet)
Width:
1.26 (in)
Height:
0.67 (in)
Depth:
1.77 (in)
Current Stock:
Adding to cart… The item has been added
Description
SFL 1502C, Left-Hand, Face Grooving Style, Face Grooving Blade with a 150.00mm Minimum Face Groove Diameter for Face Grooving Applications
Additional Information
Tool Style:
SF
Material:
Steel
Grooving Type:
Face Grooving
Application:
Face Grooving
Hand:
Left-Hand
[CDX] Max Depth of Cut (mm):
0.32
[DAXN] Minimum Face Groove Diameter (mm):
150.00
[DAXX] Maximum Face Groove Diameter (Decimal Inch):
9.8425
[DAXX] Maximum Face Groove Diameter (mm):
250.00
Coolant Through (Yes/No):
No
Insert Holding Method:
Top Clamp
Unit (inch/mm):
mm
Feature 1:
Left-Hand Face Grooving Blade
Feature 2:
9.8425 inch Maximum Face Groove Diameter
Feature 3:
Compatible with GVFL 500~600-040C Inserts
ANSI Part Number:
SFL1502C
ISO Part Number:
SFL-1502C
US Stock:
0
Worldwide Stock:
1
Compatible Inserts (Partial):
GVFL500~600-040C
Old Material Number:
8813499
Compatible Toolholder (Partial):
GFVSL…-HC, GFVTL…-HC
[CDX] Max Depth of Cut (Decimal Inch):
0.0126
[DAXN] Minimum Face Groove Diameter (Decimal Inch):
5.9055
