SFL 351B, Face Grooving Blade

SFL 351B, Face Grooving Blade

SKU:
THC05059
|
UPC:
4960664010875
$63.18
(No reviews yet)
Width:
1.26 (in)
Height:
0.67 (in)
Depth:
1.77 (in)
Current Stock:
Adding to cart… The item has been added
Description
SFL 351B, Left-Hand, Face Grooving Style, Face Grooving Blade with a 35.00mm Minimum Face Groove Diameter for Face Grooving Applications
Additional Information
Tool Style:
SF
Material:
Steel
Grooving Type:
Face Grooving
Application:
Face Grooving
Hand:
Left-Hand
[CDX] Max Depth of Cut (mm):
4.80
[DAXN] Minimum Face Groove Diameter (mm):
35.00
[DAXX] Maximum Face Groove Diameter (Decimal Inch):
1.9685
[DAXX] Maximum Face Groove Diameter (mm):
50.00
Coolant Through (Yes/No):
No
Insert Holding Method:
Top Clamp
Unit (inch/mm):
mm
Feature 1:
Left-Hand Face Grooving Blade
Feature 2:
1.9685 inch Maximum Face Groove Diameter
Feature 3:
Compatible with GVFL 250~350-020B, GVFL 300-150BR Inserts
ANSI Part Number:
SFL351B
ISO Part Number:
SFL-351B
US Stock:
0
Worldwide Stock:
1
Compatible Inserts (Partial):
GVFL250~350-020B, GVFL300-150BR
Old Material Number:
8813500
Compatible Toolholder (Partial):
GFVSL…-HB, GFVTL…-HB
[CDX] Max Depth of Cut (Decimal Inch):
0.1890
[DAXN] Minimum Face Groove Diameter (Decimal Inch):
1.3780
Series Description (PeopleSoft):
GFV Grooving
Series Description:
GFV Grooving
