SFR 352B, Face Grooving Blade

SFR 352B, Face Grooving Blade

SKU:
THC05060
|
UPC:
4960664010882
$63.18
(No reviews yet)
Width:
1.26 (in)
Height:
0.67 (in)
Depth:
1.77 (in)
Current Stock:
Adding to cart… The item has been added
Description
SFR 352B, Right-Hand, Face Grooving Style, Face Grooving Blade with a 35.00mm Minimum Face Groove Diameter for Face Grooving Applications
Additional Information
Tool Style:
SF
Material:
Steel
Grooving Type:
Face Grooving
Application:
Face Grooving
Hand:
Right-Hand
[CDX] Max Depth of Cut (mm):
5.30
[DAXN] Minimum Face Groove Diameter (mm):
35.00
[DAXX] Maximum Face Groove Diameter (Decimal Inch):
1.9685
[DAXX] Maximum Face Groove Diameter (mm):
50.00
Coolant Through (Yes/No):
No
Insert Holding Method:
Top Clamp
Unit (inch/mm):
mm
Feature 1:
Right-Hand Face Grooving Blade
Feature 2:
1.9685 inch Maximum Face Groove Diameter
Feature 3:
Compatible with GVFR 400
Feature 4:
490-020B, GVFR 400-200BR Inserts
ANSI Part Number:
SFR352B
ISO Part Number:
SFR-352B
US Stock:
0
Worldwide Stock:
1
Compatible Inserts (Partial):
GVFR400~490-020B, GVFR400-200BR
Old Material Number:
8806823
Compatible Toolholder (Partial):
GFVSR…-HB, GFVTR…-HB
[CDX] Max Depth of Cut (Decimal Inch):
0.2087
[DAXN] Minimum Face Groove Diameter (Decimal Inch):
1.3780
