SHC124070, Adjustable Boring Bar Sleeve

SHC124070, Adjustable Boring Bar Sleeve

SKU:
THC07682
$375.01
(No reviews yet)
Width:
1.38 (in)
Height:
1.14 (in)
Depth:
5.91 (in)
Current Stock:
Adding to cart… The item has been added
Description
SHC124070 Adjustable Boring Bar Sleeve with a 40.00mm Shank Diameter and a 12.00mm Bar Hole Diameter
Additional Information
Tool Style:
SHC
Material:
Steel
Application:
Boring
[DCB] Connection Bore Diameter (mm):
12.00
[H] Shank Height (mm):
38.00
Shank Type:
Flange Shank
[DCON] Connection Diameter (mm):
40.00
Insert Holding Method:
n/a
Unit (inch/mm):
mm
Feature 1:
Rigid Design
Feature 2:
Adjustable Bar Overhang Length
Feature 3:
For Boring Applications
Feature 4:
Compatible with A12..-…, C12..-…, E12..-…, S12..-… Boring Bars
ANSI Part Number:
SHC124070
ISO Part Number:
SHC1240-70
Old Material Number:
8813522
Clamp Screw:
HS10X10 (Front), HS10X10 (Back), HH3X6 (for Back Cover)
Back Cover:
SHL-4
Wrench (for Clamp Screw):
LW-5 (Front Screw), LW-5 (Back Screw), LW-2.5 (for Back Cover Screw)
Product Notes 1:
*To stabilize the Toolholder and to prevent coolant leaks, tighten all 4 screws of coolant sleeve securely.
Compatible Bars (Partial):
A12..-…, C12..-…, E12..-…, S12..-…
[LF] Functional Length (mm):
86.00
[LH] Head Length (mm):
16.00
[DCB] Connection Bore Diameter (Decimal Inch):
0.4724
[H] Shank Height (Decimal Inch):
1.4961
[DCON] Connection Diameter (Decimal Inch):
1.5748
[LF] Functional Length (Decimal Inch):
3.3858
[LH] Head Length (Decimal Inch):
0.6299
[LS] Shank Length (mm):
70.00
[LS] Shank Length (Decimal Inch):
2.7559
Series Description (PeopleSoft):
General Purpose Boring Bar
Series Description:
General Purpose Boring Bar
